ETC Gio Installation Manual

E T C S e t u p G u i d e
®
Universal Fader Wing Installation
I n tr o d u c ti o n
The Universal Fader Wings are peripheral devices that can expand the functionality of your ETC
®
Eos , Eos Ti
available in two different sizes: 2 x 10 (20 faders) and 2 x 20 (40 faders). Fader wings can be
physically attached to a console or they can stand alone and attach using a USB cable and an
external power supply. For information about the 1x20 fader wing, please see the Universal Fader
Wing - 1x20 Setup Guide, which is available for download from the ETC website at
www.etcconnect.com.
N o t e :
R u l e s o f C o n n e c t i o n
C A U T I O N :
Universal Fader Wings may be connected together and then connected to Eos, Eos Ti, Gio, Ion,
Cobalt, Congo, or Congo jr consoles using a USB cable. They may also be physically attached to
both Ion and Congo jr consoles. When attaching fader wings with a USB cable, one external power
supply must also be used.
Rule One
Eos Family
Your entire system is limited to a total of 300 faders per processor (Eos, Eos Ti, Gio, Ion, RPU, RVI).
N o t e :
Co balt/Congo F amily
Cobalt and Congo consoles support up to 80 Master Playback faders, 40 of which are built into the
console itself. Congo can support the connection of additional faders (up to two 2x10, or 1 2x20
wing, or the Master Playback Wing) via USB cable. The wing requires an external power supply
when used via USB cable.
Congo jr consoles can support up to a total of 80 Master Playback faders (console + wings), in any
combination of wings, as long as the total fader count is 80 or fewer.
N o t e :
Corporate Headquarters
London, UK
Rome, IT

Holzkirchen, DE
Hong Kong
Service: (Americas)
Web: www.etcconnect.com
4310M2110
Uni ver s al F ad er Wi ng Set u p Gui de
™ ® ® ®
, Gio , Ion , Cobalt , Congo
The 2 x 10 and 2 x 20 Universal Fader Wings are compatible with Eos v1.3.1 or
higher (running on Eos, Eos Ti, Gio, Ion, Net3 RVI,
Family Client or Offline Software in Eos, Gio, or Ion Mode, running on a PC. The
Mac OS is not supported). Fader Wings are supported on Cobalt, Congo, and
Congo jr consoles with version 6.x.x software and above. The software is
available from the ETC website at www.etcconnect.com. Consult the user manual
and/or release notes of those control systems to determine the level of
compatibility and complete functionality of the wings within those systems.
.
Disconnect power from your console before connecting or removing fader wings.
"Hot swapping" (connecting or disconnecting with a powered, running console) is
not advised and may cause data loss or other unexpected results.
™
Element does not support external fader wings.
®
Congo Kid does not support external wings.
3031 Pleasant View Road, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA

Unit 26-28, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK

Via Pieve Torina, 48, 00156 Rome, Italy

Ohmstrasse 3, 83607 Holzkirchen, Germany

Room 1801, 18/F, Tower 1 Phase 1, Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong

service@etcconnect.com (UK)

Copyright © 2014 ETC. All Rights Reserved.

Rev F Released 2014-07 ETC intends this document to be provided in its entirety.
  
® ™
, or Congo jr lighting control system. Fader wings are
Tel +44 (0)20 8896 1000

Tel +39 (06) 32 111 683 Fax +44 (0) 20 8752 8486

Tel +49 (80 24) 47 00-0 Fax +49 (80 24) 47 00-3 00
 
service@etceurope.com (DE) techserv-hoki@etcconnect.com

Product information and specifications subject to change.

Pag e 1 of 6
