Installing Remote Focus Unit
1. Turn RFU power switch Off.
2. Insert the RFU cable into the connector on the back of the
console (or an ETCNet Interface) labeled RFU.
3. Turn RFU power switch On .
4. Follow configuration instructions on next page.
RFU console connector
XLR 6-pin female
RFU pinout
1 Data (+) (to RFU)
2 Data (–)
3 Data (+) (from RFU)
4 Data (–)
5 Common (AC ground)
6 +12 Vdc (fused, 2A)
