Obsession Console
Main DIP switch settings - Serf Boards
A set of DIP switches are located inside the console at the front
left corner of the circuit board to the left of the fans. The settings
of these DIP switches need only be changed if you change the
status of a Full Tracking Backup system.
To change the DIP switch settings, raise the top panel and lock it
in upright position. Find the switches and adjust the settings as
shown on the list below.
Switches are either On (Closed) or Off (Open). Obsession does
not use DIP switches 2-5 . DIP switch 1 must be Off or the
system will not start.
DIP Switch
1
Off (Open)
2, 3, 4 & 5
6
On (Closed)
Off (Open)
7
On (Closed)
Off (Open)
8
On (Closed)
Off (Open)
Function
Factory Use Only
Should always be set
Unused
Console mode on start up
Backup (B)
Master (A)
Full Tracking Backup
Track ng on
T a king off
Network
Network installed
Network not installed
