Using ETCNet
ETCNet is a proprietary communications protocol based on the
IEEE standard 802.3, also known as Ethernet™. It lets you inter-
connect Obsession devices in a variety of configurations. These
network devices include Obsession lighting control consoles,
Designer's Remote Consoles, Remote Interfaces, Remote Video
Interfaces, and Processor Units that provide Full Tracking Backup
capability. Through these devices, you can attach peripherals such
as monitors, printers, RFUs, DMX512 devices, and alphanumeric
keyboards to the network.
The console and all network devices provide connectors for three
types of ETCNet wiring. The connector you use depends on the
wiring installed at your location. For more information about
wiring choices, see the ETCNet Planning and Installation Gu de .
To attach Obsession to ETCNet, insert the network con ecto into
the appropriate console connector (BNC, RJ45 or DB15 Attach
other devices to the interface device as described elsewhere in
this manual.
To activate ETCNet, adjust the settings of j mpe
console's logic board.
1. Loosen the two large, gray screws on the front panel that se-
cure the face panel.
2. Raise the face panel and lo k it
3. Set the jumpers and/o DIP switches as described in Appen-
dix B, DIP switch and jumper settings on page 337.
4. Close the face p nel and secure it with the screws.
