ETC Obsession User Manual page 151

Chapter 11 Submasters
Submaster pages
Obsession's two submaster pages double the number of possible
submasters to 96 for Obsession and Obsession 3000 and 48 for
Obsession 600.
Obsession displays the message Submaster page: 1 (or
Submaster page: 2) in the upper right corner of the Playback
display . To switch the page, press [Sub Page], enter [1] or [2], and
press [Enter].
When you load a new page, any submasters set at a level above
zero remain at their current settings until you move them to their
home position. The new submasters then load. This prevents the
stage from going black or changing levels when you switch
pages. Previous page submasters' LEDs flash slowly .
Note: When you read a new show from a disk, the con ole loads
the same page that was loaded from the previous show A y
submasters on stage when you read a new show remain on stage
until you move their sliders to the home position Move sliders to
home to load new submasters.
Submaster LEDs
Each submaster slider has an LED below it. The LED's color and
state indicates the current s te of that submaster.
Color State
Off Off
Green Solid
Green Slow Blink
Green Fast Blink
Red Solid
Red Slow Blink
Red Fast Blink
Meaning
Submaster not loaded in this page.
Additive submaster loaded in this page.
Additive submaster loading into this page,
Loads when slider reaches home position(s).
Additive submaster on timed hold. Press
bump button to begin downfade.
Inhibitive submaster loaded in this page.
Inhibitive submaster loading into this page,
Loads when slider reaches home position(s).
Inhibitive submaster on timed hold. Press
bump button to begin downfade.
151
