Icom IP1000C Instruction Manual page 78

4
ABOUT THE SETTING SCREEN
7. [RoIP Server Settings] Menu
■ Telephone Gateway Interconnection Group
If the courses of the Telephone Gateway Interconnection to the VE-PG3s are made into a group, the unused
course in the group can be selected to dispatch.
1
2
3
(This is only an example.)
No. �����������
1
Name ����������
2
Telephone Gateway
3
Interconnection Number �
<Add> ���������
4
<Reset> ��������
5
[RoIP Server Settings]–[Telephone Gateway Interconnection]
Select the number that is registered to a group.
L Up to 20 groups can be registered.
Enter the group name. (Up to 31 characters)
Select the Telephone Gateway Interconnection to register to the group.
Click to add the entries.
Click to restore the settings.
L You cannot restore after clicking <Add>.
4-25
4 5
