Icom IP1000C Instruction Manual page 180

4
ABOUT THE SETTING SCREEN
9. [Common Settings] Menu
■ Profile
Individually assign an ID list, message list or receive notification tone to the group that the WLAN transceivers
belong to.
L After the setting is completed, you must reboot the WLAN transceivers.
1
2
3
4
5
(This is only an example.)
No. �����������
1
Name ����������
2
Wireless LAN ������
3
ID List ���������
4
Message List ������
5
Select a profile between 1 and 100, to assign to the WLAN transceivers
belong to.
Enter a profile name of up to 31 characters.
The profile name is displayed in the [Profile List] item in the [Profile]
screen.
Select the wireless LAN setting that is commonly used by the WLAN
transceivers in the group.
• Transceiver's Setting
Uses the last wireless LAN setting that was set by the programming
software or IP1000C.
• 1 (Name) to 20 (Name)
Select a number with wireless LAN name that was entered in the
Wireless LAN screen.
Select an ID list that are commonly used by the WLAN transceivers in
the group.
L Select an ID number that is registered in the ID list screen.
Select a message list that are commonly used by the WLAN
transceivers in the group.
L Select a message number that is registered in the Messages.
4-127
[Common Settings]–[Profile]
(Default: Transceiver's Setting)
(Default: Disable)
(Default: Disable)
