Icom IP1000C Instruction Manual page 137

4
ABOUT THE SETTING SCREEN
8. [Transceiver Settings] Menu
■ Transceiver Settings [IP110H]
28
29
30
31
32
(This is only an example.)
[P1] ~ [P5] ........................
28
IP110H
[P1]
VS-3
• Playback Recording
Holding down the programmable key for 1 second displays the
recorded log screen. Select and push [ENT] on the IP110H to start
playing back the recorded audio.
• Temporary Audio Level
Holding down the programmable key for 1 second increases or
decreases the Audio output volume, based on the current volume on
the IP110H.
Select the increasing or decreasing level to between "–32" and "+32"
or "0" (disabled.)
[P2]
[P3]
[P4]
[P5]
[Transceiver Settings]–[Transceiver Settings]
4-84
