  • Page 1 IDAS TRUNKING CONTROLLER S-15217XZ-C1 February 2016...
  • Page 2 Addresses are provided on the inside back cover for your convenience. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia, Australia, New Zealand, and/or other countries.
  • Page 3 TABLE OF CONTENTS SECTION SPECIFICATIONS SECTION PARTS LIST SECTION BOARD LAYOUTS SECTION BLOCK DIAGRAM SECTION SCHEMATIC DIAGRAM...
  • Page 4 SECTION 1. SPECIFICATIONS ■ General • Power supply voltage: 12 V DC nominal (negative ground) • Current drain (approximately): 600 mA • Operating temperature range: 0˚C to +40˚C, 32˚F to +104˚F • Dimensions (projections not included): 483 (W) × 44 (H) × 219 (D) mm: 19(W) × 1.7(H) × 8.6(D) inches •...
  • Page 5 SECTION 2 SECTION 2 PARTS LIST [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION IC21 6910025580 S.DC BD95861MUV-E2 14.3/51.9 D3251 1750003390 S.ZEN RCLAMP1521P.TCT <MSK> 184.1/54.9 IC51 1110006260 S.IC BD5242G-TR 19.9/12.2 D3252 1750003390 S.ZEN RCLAMP1521P.TCT <MSK> 184.1/57.0 IC101 1180004450 S.REG RT8296BLZSP <MAX> 17.1/85.8 D3253 1750003390 S.ZEN...
  • Page 6 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R507 7030010040 S.RES ERJ2GEJ-JPW 39.0/60.6 R1209 7030014310 S.RES ERJ2GEJ241X (240) 67.7/70.3 R508 7030005050 S.RES ERJ2GEJ 103 X (10K) 49.3/59.0 R1210 7030014310 S.RES ERJ2GEJ241X (240) 68.7/70.3 R510 7030010040 S.RES ERJ2GEJ-JPW 39.5/58.7 R1302 7030005240 S.RES ERJ2GEJ 473 X (47K) 116.9/34.7...
  • Page 7 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R2152 7030010900 S.RES ERJ3GEYJ 750 V (75) 87.2/141.1 C501 4030020300 S.CER GRM21BB31C475KA87L 43.4/44.5 R2153 7030010900 S.RES ERJ3GEYJ 750 V (75) 84.1/141.1 C502 4030020300 S.CER GRM21BB31C475KA87L 36.3/48.2 R2154 7030010900 S.RES ERJ3GEYJ 750 V (75) 81.1/141.1 C503 4030020300 S.CER GRM21BB31C475KA87L...
  • Page 8 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C1602 4030019990 S.CER C1005 JB 1C 104K-T 109.5/52.9 C2008 4030019990 S.CER C1005 JB 1C 104K-T 99.5/105.0 C1603 4030019990 S.CER C1005 JB 1C 104K-T 98.5/53.5 C2009 4030019990 S.CER C1005 JB 1C 104K-T 100.6/110.8 C1604 4030019990 S.CER C1005 JB 1C 104K-T...
  • Page 9 [MAIN UNIT] [LED UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C3212 4030019990 S.CER C1005 JB 1C 104K-T 111.7/68.4 1590004150 S.TRA DRC9114T0L 55.7/3.0 C3213 4030019990 S.CER C1005 JB 1C 104K-T 111.7/67.5 1590004150 S.TRA DRC9114T0L 75.7/3.0 C3251 4030019990 S.CER C1005 JB 1C 104K-T 105.7/62.7 1590004150 S.TRA DRC9114T0L...
  • Page 10 SECTION 3. BOARD LAYOUTS • MAIN UNIT B-8325B (TOP VIEW) • LED UNIT B-8432A (TOP VIEW) J2101 J3101 C3318 R3353 S3304 J2201 J3101 T2221 T2151 T2121 C3104 FI2224 FI2223 FI2222 FI2221 C3103 FI2153 FI2154 FI2152 FI2151 FI2158 FI2157 FI2156 FI2155 FI2128 FI2127 FI2126...
  • Page 11 • MAIN UNIT B-8325B (BOTTOM VIEW) • LED UNIT B-8432A (BOTTOM VIEW) C2101 C2201 C2025 C2011 EP2004 C2026 C2036 C2037 C2047 C2043 C2024 R2053 EP2002 C2032 R2013 R2014 C2058 C2060 R2020 C2001 C2002 C1684 C1016 C1008 C1004 R1066 R1065 C1702 C1027 C3205 C1699...
  • Page 12 SECTION 4. BLOCK DIAGRAM NOR Flash SD Card DDR3 DRAM x2 NAND Flash (64 MB) Connecter (1 GB) (1 GB x2) JTAG (8 GB) (8192 MB x2) SPI ROM EEPROM VDD5V1 VDD1R1 (8 GB) (512 MB) DC/DC VDD2R5V VDD3R3VPHY JTAG SDIO Target(Device) RJ45 Trans...
  • Page 13 SECTION 5. SCHEMATIC DIAGRAM • MAIN UNIT (1/9) VDD12V FSMD250 CPFC6D36 BD5329G EP501 VDD1R8V 4 NC IC501 MPZ1608S101A VDD 3 C520 D7 VBACKUP VOUT 2 5 CT EP502 VDD5V B6 VCC7 VRTC VDD1R1V2 MPZ1608S101A D8 VCC5 LDO3 4.7k EP503 VDD3R3V2 LDO4 VDD3R3V2 MPZ1608S101A...
  • Page 14 • MAIN UNIT (2/9) IC1001 IC1001 C1608 EP1609 VDD1R1V3 AVDD_PLL_CPU VDD_CPU VDD2R5V VDD_CPU AVSS_PLL_CPU MPZ1608S101A VDD_CPU EP1610 AA22 C1609 VDD_CPU AVDD_PLL_AMBA AB15 VDD_CPU AVSS_PLL_AMBA MPZ1608S101A AB17 VDD_CPU EP1611 AB19 C1610 VDD_CPU AVDD_PLL_MAC VDD1R1V1A AB21 VDD_CPU AVSS_PLL_MAC MPZ1608S101A EP1601 EP1612 C1611 VDD1R1V1 AVDD_PLL_I2S0 VDD_SOC...
  • Page 15 • MAIN UNIT (3/9) VDD1R5VDDR VDD1R5VDDR DDR_A15 DDR_DQ15 DDR_A15 DDR_DQ31 DQU7 DQU7 DDR_A14 DDR_DQ14 DDR_A14 DDR_DQ30 DQU6 DQU6 DDR_A13 DDR_DQ13 DDR_A13 DDR_DQ29 DQU5 DQU5 DDR_A12 DDR_DQ12 DDR_A12 DDR_DQ28 A12/BC DQU4 A12/BC DQU4 DDR_A11 DDR_DQ11 DDR_A11 DDR_DQ27 DQU3 DQU3 DDR_A10 DDR_DQ10 DDR_A10 DDR_DQ26 A10/AP...
  • Page 16 • MAIN UNIT (4/9) VDD3R3V VDD3R3V AC26 VDD3R3V IC1001 ADQ0 NFC_ADQ0 AC25 ADQ1 NFC_ADQ1 AC24 ADQ2 NFC_ADQ2 AB23 ADQ3 NFC_ADQ3 AB25 ADQ4 4.7k IC1301 ADQ0 4.7k R1305 NFC_ADQ4 AB26 R1352 ADQ5 ADQ1 NFC_ADQ5 AB27 ADQ6 ADQ2 4.7k R1307 NFC_ADQ6 AA24 ADQ7 ADQ3 4.7k...
  • Page 17 • MAIN UNIT (5/9) L2SW VDD2R5LAN TXCLK_0 R2051 IC1001 R2052 TXCLK_1 MAC0_GTX_CLK MAC1_GTX_CLK MAC0_TX_CLK MAC1_TX_CLK TXEN_0 R2036 R2041 TXEN_1 MAC0_TX_EN MAC1_TX_EN MAC0_TX_ER MAC1_TX_ER VDD2R5LAN TXD0_0 R2037 R2042 TXD0_1 MAC0_TXD0 MAC1_TXD0 TXD1_0 R2038 R2043 TXD1_1 MAC0_TXD1 MAC1_TXD1 TXD2_0 R2039 R2044 TXD2_1 MAC0_TXD2 MAC1_TXD2 TXD3_0...
  • Page 18 • MAIN UNIT (6/9) DLP11SN121SL2 FI2121   1 CH0_P0 CH0_N0 DLP11SN121SL2 FI2122   1 CH0_P1 CH0_N1 DLP11SN121SL2 FI2123   1 CH0_P2 CH0_N2 DLP11SN121SL2 FI2124   1 CH0_P3 CH0_N3 VDD2R5LAN J2101 DLP11SN121SL2   FI2125   1 CH1_P0 CH1_N0 DLP11SN121SL2 FI2126   1 CH1_P1 DLP11SN121SL2 ATPL-361R...
  • Page 19 • MAIN UNIT (7/9) IC1001 USB3DRD_TXP USB3H_TXP USB3DRD_TXP USB3H_TXP USB3DRD_TXM USB3H_TXM USB3DRD_TXM USB3H_TXM USB3DRD_RXP USB3H_RXP USB3DRD_RXP USB3H_RXP USB3DRD_RXM USB3H_RXM USB3DRD_RXM USB3H_RXM USB3DRD_DP USB3H_DP USB3DRD_DP USB3H_DP USB3DRD_DM USB3H_DM USB3DRD_DM USB3H_DM USB3DRD_REFCLK_IP USB3H_REFCLK_IP R3259 R3201 R3251 R3260 USB3DRD_REFCLK_IM USB3H_REFCLK_IM USB3DRD_RESREF USB3H_RESREF USB3DRD_VBUS_5V USB3H_VBUS_5V USB3DRD_VBUS USB3H_VBUS...
  • Page 20 • MAIN UNIT (8/9) PCIE0 IC1001 PCIE0_TXP VDD3R3VPCIE0 C1501 VDD1R5VPCIE0 PCIE0_TXP PCIE0_TXM PCIE0_TXM C1502 PCIE0_RXP J1501 PCIE0_RXP PCIE0_RXM PCIE0_RXM PCIE0_WAKE PCIE0_RESREF PCIE1_TXP PCIE0_CLKREQ PCIE1_TXM PCIE1_RXP PCIE0_REFCLK_P PCIE1_RXM PCIE0_REFCLK_M PCIE1_RESREF R1515 PCIE0_REFCLK_IP PCIE0_REFCLK_IM PCIE1_REFCLK_IP PCIE1_REFCLK_IM R1506 PCIE0_REFCLK_P PCIE0_NRST PCIE0_RXM R1507 PCIE0_REFCLK_OP PCIE0_REFCLK_M PCIE0_RXP PCIE0_REFCLK_OM...
  • Page 21 • MAIN UNIT (9/9) VDD3R3V2 L2SW VDD3R3V2 X3301 IC3307 R3301 GPIO61 IC1001 X3302 R3303 R3304 SYS_XO CLKOUT/GPIO61 SYS_XI S3304 EXT_INTR0 RTC_XI EXT_INTR1 EXT_INT2 RTC_XO EXT_INTR2 LDO_OUT EXT_INTR3 JTAG_NTRST JTAG_NTRST/GPIO56 PWR_SDA JTAG_TCK INT SW JTAG_TCK/GPIO58 PWR_SCL PWR_BOTTOM JTAG_TMS JTAG_TMS/GPIO57 JTAG_TDI JTAG_TDI/GPIO59 EFUSE_VDDQ JTAG_TDO JTAG_TDO/GPIO60...
  • Page 22 Highway 17A Delta, B.C., V4K 5B8, Canada : http://www.icomspain.com Phone : +1 (604) 952-4266 Fax : +1 (604) 952-0090 E-mail : icom@icomspain.com : http://www.icomcanada.com E-mail : info@icomcanada.com Blacksole House, Altira Park, Herne Bay, Kent CT6 6GZ, UK Phone : +44 (0) 1227 741741...
  • Page 23 S-15217XZ-C1 1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2016 Icom Inc.
