Icom IP1000C Instruction Manual page 244

6
FOR YOUR INFORMATION
2. How to connect to the IP1000C using Telnet
For Windows 10: Before performing the following procedure, turn ON [Telnet Client] from the screen that is
®
displayed when "Turn Windows features on or off" is entered in the search box on the taskbar.
■ How to connect
1. Start up Windows.
2. I nput "telnet.exe" in the search box on the taskbar, and then push [Enter].
3. The Telnet screen appears, then input the appropriate address, as shown below.
Microsoft Telnet>open IP1000C's LAN IP address. (Example: open 192.168.0.1)
4. Input login ID and password, and then push [Enter].
login: admin
password: admin (The IP1000C's default password)
5. When the Telnet access is successful, "IP1000C #" is displayed on the Telnet screen.
■ How to use the [CONSOLE] port
The IP1000C can be configured using a terminal software. (Optional OPC-1402A is required.)
Set the COM port as shown below, to communicate with the IP1000C.
COM port settings:
• COM port number: The port number that the optional OPC-1402A is connected to.
• Bits per second: 115200 (bps)
• Data bits: 8
• Parity: None
• Stop bits: 1
• Flow control: None
After settings are completed, push [Enter] to display "IP1000C #."
■ About Telnet commands
The following commands can be used with the Telnet function.
Command list �������
Command help ������
Automatic complement ��
Push the [Tab] key to display the Telnet command list.
After typing a Telnet command, push the [Tab] key to display the sub
command list.
After typing "help," enter a command to display the command
description.
Example: "help save" (the "save" command description is displayed.)
After typing the first few characters of the command, push the [Tab] key.
The rest of the characters for the command are automatically entered.
Example: "n" + [Tab] -> network
Suggested commands are displayed.
Example: "res" + [Tab] -> reset, restart
6-4
