Table E-4
(Cont.) Disk Backplane Components
Component Name
IPMI Type
(Oracle ILOM CLI
Targets)
/SYS/DBP/HDD[0- x ]/
Discrete
NVME/PRSNT
sensor
/SYS/VREG_DBP_ERR Discrete
sensor
/SYS/VREG_USB_ERR Discrete
sensor
Drive Components
The following table lists the hard disk drive (HDD) and solid state drive (SSD) components.
Table E-5
Drive Components
Component Name
IPMI Type
(Oracle ILOM CLI
Targets)
FRU
/SYS/DBP/HDD[0- x ]
/SYS/DBP/HDD[0- x ]/
Discrete
sensor
PRSNT
/SYS/DBP/HDD[0- x ]/
Discrete
STATE
sensor
/SYS/DBP/HDD[0- x ]/
Indicator
SERVICE
/SYS/DBP/HDD[0- x ]/
Indicator
OK2RM
/SYS/DBP/HDD[0- 3 ]/
FRU
NVME
/SYS/DBP/HDD[0- 3 ]/
Discrete
sensor
NVME/PRSNT
FRU
/SYS/MB/SSDR[0-1]
/SYS/MB/SSDR[0-1]/
Discrete
sensor
PRSNT
Description
NVMe device presence
Disk backplane voltage regulator-down
(VRD) error (Hidden)
Universal Serial Bus (USB) VRD error
(Hidden)
Description
Hard disk drive FRU
Hard disk drive presence
Writable multistate, slot/connector sensor
type, per IPMI
Hard disk drive Fault-Service Required
LED
Hard disk drive OK to Remove LED
NVMe drive FRU
NVMe device presence
Internal M.2 SSD riser (2) FRU
Solid-state drive (SSD) riser presence (2
risers)
Drive Components
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-DEASSERTED
02h-ASSERTED
01h-DEASSERTED
02h-ASSERTED
Values (if applicable)
From host
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-FAULT_STATUS
02h-IDENTITY
04h-INSTALLED
20h-SLOT_POWER_OFF
Color: Amber
Location: HDD
Off: Normal
On: Hard disk drive was
diagnosed as faulty.
Color: Blue
Location: HDD
Off: Normal
On: Drive is ready to remove.
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Appendix E
E-5
