Servicing Fan Modules

This section describes how to service fan modules and the fan tray.
Fan modules are replaceable components that do not require you to power off the server
before servicing. For more information about replaceable components, see
Breakdown
Fan modules are located in the front of the server.

Remove a Fan Module

You do not have to power off the server to service fan modules.
Caution:
When removing and replacing a fan module in the Exadata Server X10M, you must
complete the entire procedure within 60 seconds to maintain adequate cooling in
the system. Remove and replace only one fan module at a time. Ensure that you
have obtained the replacement fan module and that is it is ready for installation
before starting the replacement procedure.
Each fan module contains one fan, with two fan motors per fan. The two fan motors
provide separate tachometer signals so that the fan module reports two tach signals
to Oracle ILOM. Even if only one fan motor is faulted within the fan module, the
Oracle ILOM service processor detects that two fan motors have failed to spin while
the fan module is removed. If the fan module is not replaced within 60 seconds of
removal, Oracle ILOM will take the protective action to shut down the system to
prevent thermal damage to the system.
If the cover is not installed within 60 seconds, the system may shutdown due to
over-temperature or a PCIe card may overheat, potentially damaging it.
Extend the server to the maintenance position.
1.
See
To access the fan modules, remove the server top cover.
2.
See
Identify the faulty fan module.
3.
Each fan module has a fan service action required status indicator (LED) that is located
next to the module. If the LED is amber, the fan has failed. The location of the fan status
LED is shown in the following figure.
and Replaceable Components.
Extend the Server to the Maintenance
Remove the Server Top Cover.
Position.
Illustrated Parts
