Replaceable Components - Oracle Exadata X10M Service Manual

Callout
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18

Replaceable Components

This table lists server replaceable components and provides associated links to
service replacement instructions.
Table 1-1

Replaceable Components

Component Description
Service
Instructions
Storage drives
Storage drive configurations can be comprised of NVMe solid state drives (SSDs) or
SAS-3 hard disk drives (HDDs). Configurations may include up to four 2.5-inch hot-
pluggable PCIe-based NVMe SSDs or up to twelve 3.5-inch hot-pluggable SAS-3
HDDs.
Power supplies
Two fully redundant AC-powered power supplies. PS0, PS1
Fan modules
Six fan modules FM0-5 cool server components.
Fan Tray One Fan Tray. See
Description
Storage drives, up to twelve 3.5-inch hot-pluggable SAS-3 LFF HDDs in 12-Drive
backplane
Four storage drive bay cages
12-Drive backplane (DBP)
System chassis
Front LED indicator module and temperature sensor (FIM)
Six fan modules (FM0-5)
Fan tray
Motherboard assembly (MB)
Processors (P0, P1) and heatsinks (Single-processor systems contain only a single
processor in socket P0; socket P1 contains a cover to protect processor socket pins.)
24 DIMMs (Twelve DIMMs are supported in single-processor systems and the
DIMMs must be installed in P0 DIMM sockets.)
Internal M.2 SSD memory with two internal M.2 Risers
Top cover
Air baffle
System RTC battery
PCIe card shroud (9-slot PCIe card back panel)
(Optional) Oracle RoT card
Nine HHHL PCIe cards
PCIe slots 1 through 4 are nonfunctional in single-processor systems.
Two power supplies (PS0, PS1)
Fan modules
Chapter 1
Replaceable Components
Service
Level
Hot
service
Hot
service
Hot
service
Cold
service
1-12
