Oracle Exadata X10M Service Manual page 14

Feature Exadata Server X10M System Components
9-slot PCIe 9-slot PCIe Configuration
9-slot PCIe card back panel: Exadata Server X10M supports up to nine half-height PCIe
Configuration
cards. Up to nine PCIe Gen5 vertical card slots are supported when the low profile Add In
Card (AIC) chassis is utilized.
Up to nine PCIe card Gen5 slots are supported in dual-processor systems.
1.
Slot 1 - PCIe5 x16 electrical interface
2.
Slot 2 - PCIe5 x16 electrical interface
3.
Slot 3 - PCIe5 x8 electrical interface
4.
Slot 4 - PCIe5 x8 electrical interface
5.
Slot 5 - PCIe5 x16 electrical interface
6.
Slot 6 - PCIe5 x8 electrical interface, x16 electrical interface with motherboard PCIe
Flyover cable attached
7.
Slot 7 - PCIe5 x8 electrical interface with motherboard PCIe cable attached
8.
Slot 8 - PCIe5 x8 electrical interface
9.
Slot 9 - PCIe5 x8 electrical interface, x16 connector
Full Height PCIe Full Height PCIe Configuration
Two Riser back panel: Up to two vertical PCIe Gen5 slots and up to four horizontal PCIe Gen
Configuration
3 and PCIe Gen 4 cards are supported.
1.
Slot 1 - PCIe5 x16 electrical interface
2.
Slot 2 - PCIe4 x16 electrical interface full-height PCIe card
3.
Slot 3 - PCIe4 not used
4.
Slot 4 - PCIe3 x1 electrical interface, full-height PCIe card
5.
Slot 5 - PCIe5 x16 electrical interface
6.
Slot 6 - PCIe4 x8 electrical interface, x16 electrical interface with motherboard PCIe
Flyover cable installed, full-height PCIe card
7.
Slot 7 - PCIe4 not used
8.
Slot 8 - PCIe3 x1 electrical interface, full-height PCIe card
PCIe Riser Two CEM Risers: Supports a single-wide PCIe CEM compliant PCIe card.
PCIe cards • Up to eight Oracle Flash Accelerator F680 PCIe Cards: 6.8 TB, NVMe PCIe 4.0
• Up to three Oracle Dual Port QSFP56 Bifurcated 2x50Gb Network Interface Cards (NICs)
• Up to three Oracle Dual Port QSFP56 2x50Gb NICs
• Up to three Oracle Dual Port CX6-LX 2x25Gb NICs (LP ADAPTER, DUAL SFP28
25GBE,CX6 LX,PCIE4 0x8)
• Up to three Oracle Dual Port CX6-DX 2x100Gb NICs (LP ADAPTER, DUAL QSFP56
200GBE,CX-6 DX,PCIE4.0x16)
• Up to three Oracle Dual Port CX7 2x200Gb NICs (Connect X-7 2x200Gbit/Sec PAM4
PCIe Gen5 X16, Ethernet NIC)
• Up to two Pensando Ortano/Elba Server Adapters, DSC-200V, 2x200GbE, Dual QSFP56
• Up to two HBAs, BROADCOM 9500-8e,12GB SAS PCIe, 8 PORT, EXTERNAL
• Up to two HBAs, BROADCOM 9500-16i, 12GB SAS PCIe, 16 PORT, INTERNAL
• One Oracle Dual Port 100 Gb RoCE Adapter
Root-of-Trust card One Root-of-Trust (RoT) card back panel slot
Power supplies Two hot-swappable and highly-redundant 1400W power supplies (PS0 and PS1)
