Description
13
Air baffle
14
System RTC battery
15
Two power supplies (PS0, PS1)
16
(Optional) Oracle RoT card
17
(Optional) Nine HHHL PCIe cards
PCIe slots 1 through 4 are nonfunctional in single-processor systems.
18
(Optional) Two PCIe Risers (2 and 6) for FHFL PCIe cards
CEM compliant riser configurations
Exadata Server X10M with 12-Drive Backplane
The following figure identifies Exadata Server X10M major components with 12-Drive
backplane.
Chapter 1
Illustrated Parts Breakdown
1-11
