Servicing the Front LED Indicator Module

This section describes how to service the front LED indicator module.
The front LED indicator module is a replaceable component that requires you to power off the
server before servicing. For more information about replaceable components, see
Parts Breakdown
Caution:
Ensure that all power is removed from the server before removing or installing a
front LED indicator module. You must disconnect the power cables before
performing this procedure.
Caution:
These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the component to fail. To avoid
damage, ensure that you follow electrostatic discharge safety measures and
antistatic practices. See

Remove the Front LED Indicator Module

Prepare the server for service.
1.
a.
b.
c.
d.
e.
Disconnect the LED indicator module cable from the motherboard.
2.
and Replaceable
Electrostatic Discharge
Power off the server.
See Powering Down the Server.
Disconnect the power cords from the power supplies.
See Disconnect Cables From the
Extend the server into the maintenance position.
See Extend the Server to the Maintenance
Attach an antistatic wrist strap to your wrist, and then to a metal area on the chassis.
See Take Antistatic Measures.
Remove the server top cover.
See Remove the Server Top
Components.
Safety.
Server.
Position.
Cover.
Illustrated
15-1
