When servicing or removing server components, attach an antistatic strap to your wrist
and then to a metal area on the chassis. Then perform procedures for servicing the
server.

Remove the Server Top Cover

Servicing some components requires that the top cover be removed.
Ensure that AC power cords are disconnected from the server power supplies.
1.
If the release button latch is in the locked position, use a Torx T15 screwdriver to turn the
2.
release button latch clockwise to the unlocked position.
Unlatch the top cover [1].
3.
Lift up on the release button on top of the server cover. Lifting the release button slides
the server cover toward the rear of the chassis for easy removal.
Note:
An antistatic wrist strap is not included in the Accessory Kit for the server.
However, antistatic wrist straps might be included with options and
components.
Note:
Fan modules and M.2 flash SSDs are hot-pluggable and do not require AC
power cables to be disconnected from the server power supplies.
