Drive Usage Information; Drive Reliability; 480Gb, M.2, Nvme Solid State Drive 8214991 Specification - Oracle Exadata X10M Service Manual

Table B-13

480GB, M.2, NVMe Solid State Drive 8214991 Specification

Specification
Device name
Manufacturing name
Form factors
PCIe interface
Features
Product Compliance
Product ecological compliance
Certifications and declarations
Table B-14

Drive Usage Information

Attribute
Operating temperature (Composite,
as reported via SMART)
Non-Operating temperature
Maximum temperature (SMART trip) Warning at 77 degrees Celsius (composite). Thermal
Error rates
Data retention
Endurance
Table B-15

Drive Reliability

Attribute
Component Design Life (Useful life)
480GB NVMe M.2 Solid State Drive Specification
Value
Product Identifier: SAMSUNG MZVL2480HBJD-00A07
Oracle Part Number: 8214991
Device Identification:
• PCIe Vendor ID: 0x144D
• PCIe Device ID: 0xA80A
• Subsystem PCIe Vendor ID: 0x144D
• Subsystem ID 0xA812
Samsung PM9A3 480GB M.2 NVMe Solid-State Drive
M.2 2280 M key
PCIe Gen4 Interface, Single port x4 lanes
NVMe PCIe Gen4 Interface
NVMe-MI
VPD is blank "FFs" as supplied
TCG Opal 2.0 compliant
• NVM Express Specification Rev. 1.4
• PCI Express Base Specification Rev. 4.0
• Enterprise SSD Form Factor Version 1.0a
• NVMe-MI Rev 1.1 (excluding VPD data)
RoHS
cUL, CE, TUV-GS, CB, BSMI, KC, VCCI, Morocco, RCM,
FCC, IC
Value
0 to 70 degrees Celsius
-40 to 85 degrees Celsius
throttling in stages until critical 85 degrees Celsius.
Thermal Shutdown at 99 degrees Celsius.
Uncorrectable Bit Error Rate (UBER): 1 sector per 10^17
bits read
3 months powered off at 40 degrees Celsius at end of
rated endurance
Drive Writes Per Day (DWPD) for 5 years: 1
PBW (at 4KB Random Write): 0.8 PB
Refer to the JEDEC JESD218A standard for SSD device
life and endurance measurement techniques.
Value
5 years
