Oracle Exadata X10M Service Manual page 134

Caution:
When reinstalling power supplies, it is important to reinstall them into the slots
from which they were removed during the motherboard removal procedure;
otherwise, the server key identity properties (KIP) data might be lost. When a
server requires service, the KIP is used by Oracle to verify that the warranty on
the server has not expired. For more information on KIP, see
Properties (KIP) Automated
• Power supplies
See Install a Power
• PCIe cards and motherboard PCIe cable
See Configure PCIe Electrical Interfaces Using the PCIe Flyover Cable
See Install a Half Height PCIe
See Install a Full Height PCIe
• SAS storage drive cables (if present)
See Install SAS Storage Drive
• Fan tray
See Install the Fan
• Fan modules
See Install a Fan
• Air baffle
To install the air baffle, the baffle must fit around the processor heatsinks, then lifted
up about 50 degrees. Locate the tabs on the air baffle so that one tab on each side is
under the lip of the fan tray, and the others are on top of the fan tray.
See Install the Air
Return the server to operation.
6.
Install the server top cover.
a.
See Install the Server Top
Return the server to the normal rack position.
b.
See Return the Server to the Normal Rack
Reconnect the power cords to the power supplies, and power on the server.
c.
See Reconnect Power and Data Cables
Verify that the power supply AC OK LED is lit.
d.
Update.
Supply.
Card.
Card.
Cables.
Tray.
Module.
Baffle.
Cover.
and
Install the Motherboard Assembly
FRU Key Identity
Position.
Power On the Server.
Chapter 12
12-15
