Oracle Exadata X10M Service Manual page 24

Table 1-1 (Cont.) Replaceable Components
Component Description
Service
Instructions
M.2 flash
Up to two hot-pluggable internal M.2 NVMe SSDs in up to two SSD Risers.
SSDs
DIMMs
Add or replace memory modules in the system.
Battery
Lithium coin-cell battery that powers CMOS BIOS and RTC real-time clock.
PCIe cards
Optional PCIe Add-in cards (AIC) that can expand server functionality.
1
PCIe Risers
Two optional PCIe Risers to accommodate Full Height PCIe Cards labeled Riser 2
and Riser 6.
Air baffle
Directs cool air towards the system components.
Motherboard
Motherboard (MB) Provides connectors for the DIMMs, processors, PCIe risers, and
assembly
other components.
Processor
Processor with heatsink that carries out the instructions of the system.
Disk backplane
4 or 12 disk backplane (DBP) provides power and communications connectors for 4
NVMe SFF or 12 SAS-3 LFF storage drives.
Front LED
FIM contains the push-button circuitry and LEDs that are displayed on the front panel. Cold
indicator
module
SAS cables
Provides SAS-3 signals between card located in PCIe slots and the disk backplane.
1 Oracle Flash Accelerator F680 PCIe Card: 6.8 TB, NVMe PCIe 4.0 in Exadata Database Server X10M, Exadata Storage Server X10M,
and Exadata Control Plane Server X10M
Chapter 1
Replaceable Components
Service
Level
Hot
service
Cold
service
Cold
service
Cold
service
Hot
service
Cold
service
Cold
service
Cold
service
Cold
service
Cold
service
service
Cold
service
1-13
