Fan Module Status Indicators; Storage Drive Status Indicators - Oracle Exadata X10M Service Manual

Table A-2
Status
Indicator
Name
Fault-
Service
Required

Fan Module Status Indicators

Each fan module has one status indicator (LED). Fan LEDs are located on the chassis fan
tray adjacent to and aligned with the fan modules, and are visible when the server top cover
is removed.
Table A-3
Status
Indicator
Name
Fan Module
Fault

Storage Drive Status Indicators

There are three status indicators (LEDs) on each drive.
Table A-4
Status
Indicator
Name
OK/Activity
Fault-
Service
Required
(Cont.) Power Supply Status Indicators
Icon Color State and Meaning
Amber OFF – Normal operation. No service action is required.
STEADY ON – The power supply (PS) detected a PS fan
failure, PS overtemperature, PS overcurrent, or PS
overvoltage or undervoltage.

Fan Module Status Indicators

Icon Color State and Meaning
Amber OFF – The fan module is correctly installed and operating within
specification.
STEADY ON – The fan module is faulty. The front TOP FAN
LED and the front and back panel Fault-Service Required LEDs
are also lit if the system detects a fan module fault.

Storage Drive Status Indicators

Icon Color
Green
Amber
State and Meaning
OFF – Power is off or installed drive is not recognized by
the system.
STEADY ON – The drive is engaged and is receiving
power.
RANDOM BLINK – There is disk activity. Status indicator
LED blinks on and off to indicate activity.
OFF – The storage drive is operating normally.
STEADY ON – The system detected a fault with the
storage drive.
Appendix A
Fan Module Status Indicators
A-3
