Server Features and Components

This section describes the components, status indicators (LEDs), connectors, ports, and storage
drives on the front and back panels of the servers.
"Server Components" on page 25
■
"X7-2 Front Panel Features" on page 27
■
"X7-2 Back Panel Features" on page 29
■
"X7-2L Front Panel Features" on page 30
■
"X7-2L Back Panel Features" on page 32
■

Server Components

Feature
Processor
Memory
Storage Drives
(Oracle Server X7-2)
System Components
One or two processors with six integrated DDR4 memory controllers per processor.
Processors with the following capabilities are supported (factory installed):
■ Intel Xeon 8168, 24 core, 2.7 GHz, 205W (Oracle Server X7-2L only)
■ Intel Xeon 8160, 24 core, 2.1 GHz, 150W
■ Intel Xeon 6140, 18 core, 2.3 GHz, 140W
■ Intel Xeon 6128, 6 core, 3.4 GHz, 115W
■ Intel Xeon 4114, 10 core, 2.0-2.2 GHz, 85W
For the latest information on processor specifications, go to the Oracle x86 servers
web site and navigate to the Oracle Server X7-2 or X7-2L page:
oracle.com/technetwork/server-storage/sun-x86/overview/index.html
Up to 12 DDR4 DIMMs per processor for a maximum of 24 RDIMMs (16 GB and
32 GB) and LRDIMMs (64 GB) with speeds up to 2667 MT/sec in dual-processor
systems.
The storage drive configuration can comprise both hard disk drives (HDDs) or solid
state drives (SSDs). The configuration includes:
■ Up to eight 2.5-inch hot-pluggable SAS3 HDDs or SATA3 SSDs, with optional
support for up to eight 2.5-inch NVM-Express (NVMe) SSDs
■ Two internal SATA/PCIe M.2 flash modules
http://www.
