System MMU

1.4.5.2.18 MMU_EMU_FAULT_AD

The MMU_EMU_FAULT_AD register is shown in
31
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Bit Field
31-0 EMUFAULTADDRES
S

1.4.5.2.19 MMU_FAULT_PC

The MMU_FAULT_PC register is shown in
31
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Bit Field
31-0 PC
144
Chip Level Resources
Preliminary
Figure 1-42. MMU_EMU_FAULT_AD
EMUFAULTADDRESS
R-0
Table 1-40. MMU_EMU_FAULT_AD Field Descriptions
Value Description
0-FFFF Virtual address of the last emulator access that generated a fault.
FFFFh
Figure 1-43
Figure 1-43. MMU_FAULT_PC
R-0
Table 1-41. MMU_FAULT_PC Field Descriptions
Value Description
0-FFFF CPU program counter value where cause MMU fault.
FFFFh
The address value is captured at MMU_EMU_FAULT_AD[31:0] EMUFAULTADDRESS bit
field.
Data-Read-access : corresponding PC.
Data-write-access : not perfect accuracy due to Posted-write.
© 2011, Texas Instruments Incorporated
Figure 1-42 and described in
and described in Table
PC
www.ti.com
Table 1-40.
0
1-41.
0
SPRUGX9 – 15 April 2011
