SGX530 Graphics Subsystem
1.5.4.1.3 System Configuration Register (OCP_SYSCONFIG)
The System Configuration Register (OCP_SYSCONFIG) is shown in
Table 1-46.
31
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 1-46. System Configuration Register (OCP_SYSCONFIG) Field Descriptions
Bit Field
31-6 Reserved
5-4 STANDBY_MODE
3-2 IDLE_MODE
1-0 Reserved
154
Chip Level Resources
Preliminary
Figure 1-49. System Configuration Register (OCP_SYSCONFIG)
Reserved
R-0
Value Description
0 Reserved.
Clock standby mode.
0 Force Standby mode.
1h No Standby mode.
2h Smart Standby mode.
3h Smart Standby mode.
Clock Idle mode.
0 Force Idle mode.
1h No idle mode.
2h Smart Idle mode.
3h Smart Idle mode.
0 Reserved.
© 2011, Texas Instruments Incorporated
Figure 1-49
6 5 4
STANDBY_MODE
R/W-2
www.ti.com
and described in
3 2 1 0
IDLE_MODE Reserved
R/W-2 R-0
