10.3.2

Notes and Restrictions on the Use of the Copy Feature

Restrictions on Leftward Image Shift
When you specify leftward image shift, the print image is shifted by the amount shown in the table below. (Unit:
mm)
The actual result, however, may vary depending on the status of the printer and/or the condition of the media.
Set Amount Shift Amount
0 0
1 0
2 0
3 2
4 2
5 4
6 4
7 6
8 6
9 8
10 8
11 10
12 10
13 12
14 12
15 14
16 14
Set Amount Shift Amount
17 16
18 16
19 18
20 18
21 20
22 21
23 22
24 22
25 24
26 24
27 26
28 26
29 28
30 28
31 30
32 30
33 33
Set Amount Shift Amount
34 33
35 35
36 35
37 37
38 37
39 39
40 39
41 41
42 41
43 43
44 43
45 45
46 45
47 47
48 47
49 49
50 49
