Text String Added to User Name
Set the string to be added to authentication information. Up to 64 characters are allowed. When [Use Added Text
String] is set to [Enabled], the fixed string must be entered here. For example, [Attribute of entered User Name] is
set to "mail", and the registered information for a user is "mail@myhost.example.com", the user normally need to
enter "ail@myhost.example.com". Instead, setting [Use Added Text String] to [Enabled] and specifying
"@myhost.example.com" in [Text String Added to User Name] allows the user to login the machine by simply
entering "mail" on the control panel, because the machine automatically add "@myhost.example.com".
Login Name
Allows you to specify a user name used to access the server. Set this only when the directory service authentication
is required. Up to 255 characters can be entered for the user name.
Password
Allows you to specify the login password for the user you have specified in [Login Name]. Up to 32 alphanumeric
characters are allowed.
Search Directory Root
Enter a string to be used as search root, using up to 255 characters.
LDAP Referrals
Allows you to specify whether to re-establish connection to another LDAP server if a currently connected LDAP
server requests to do so.
The factory default is [Disabled].
LDAP Referral Hop Limit
When using the Referral feature, specify how many times that a user is allowed to hop servers in the range of 1 to
5 times.
9
The factory default is [5] times.
