Xerox 6030/6050 Wide Format
Printer User Guide
701P41568
Version 1.8
May 2004

Advertisement

Table of Contents
loading

  Also See for Xerox 6030

  Related Manuals for Xerox 6030

  Summary of Contents for Xerox 6030

  • Page 1 Xerox 6030/6050 Wide Format Printer User Guide 701P41568 Version 1.8 May 2004...
  • Page 2 Solaris and SunOS are registered trademarks of Sun Microsystems, Inc. UNIX is a registered trademark of Open Group Company Limited XEROX®, The Document Company®, the digital X®, Xerox 6030/6050 Wide Format Printer, and Versatec are the trademarks of or licensed to XEROX CORPORATION.
  • Page 3 Preface Thank you for using the Xerox 6030/6050 Wide Format Printer User Guide (hereinafter known as 6030/6050 Wide Format). This User Guide describes the basic operations and the detailed functions of the Xerox 6030/6050 Wide Format Printer. It also includes usage precautions, safety notes, replenishing toner, replacing paper, trouble shooting and other general instructions.
  • Page 4 Conventions This User Guide uses the following symbols and conventions: < > key Indicates the keys on the Control Panel. Press the <Enter> key. Indicates the menus and display items on the screens. Select either the [On] or [Off] buttons to display [Job Name], [Owner], and [Reason] in that order.
  • Page 5: Safety Notes

    Read these safety notes carefully before using this product to ensure you operate the equipment safely. Your Xerox product and recommended supplies have been designed and tested to meet strict safety requirements. These include safety agency approval, and compliance to established environmental stan- dards.
  • Page 6 1989 Regula- tion. Customers wishing to complete safety testing should contact Xerox for advice prior to any test implementation. Xerox equipment should, however, be properly and regularly serviced and maintained at all times.
  • Page 7: Electrical Supply

    ANSWER: After safety testing, your Xerox Customer Service Engineer will provide you with a certifi- cate which details the results of all tests completed. In the event of any defect being noted, the Xerox equipment will be switched off and disconnected from the supply until the defect has been corrected.
  • Page 8: Operator Accessible Areas

    WARNING This product must be connect to a protective earth circuit. This product is supplied with a plug that has a protective earth pin. This plug will fit only into an grounded electrical outlet. This is a safety feature. To avoid risk of electric shock, contact your electrician to replace the electrical outlet if you are unable to insert the plug into it.
  • Page 9: Emergency Power Off

    • This equipment is to be used on a dedicated 20A, 208-240 Vac 60Hz circuit or 16A, 220-240 Vac 50Hz.The equipment must be connected to a grounded mains outlet. If this machine needs to be moved to a different location, contact a Xerox service representative or your authorized local representative or service support organization.
  • Page 10: Disconnect Device

    • Always follow all warnings and instructions that are marked on or supplied with the equipment. • Always exercise care when moving or relocating equipment. Please contact your local Xerox/ Fuji Xerox Service Department, or your local support organization to arrange relocation of the product to a location outside of your building.
  • Page 11: Maintenance Information

    • Never override or "cheat" any of the electrical or mechanical interlock devices. • Never operate the equipment if you notice unusual noises or odors. Disconnect the power cord from the electrical outlet and contact your local Xerox/Fuji Xerox Service Representative or Service Provider immediately.
  • Page 12: For Consumables

    Changes and modifications to this equipment not specifically approved by Xerox/ Fuji Xerox may void the user's authority to operate this equipment. Shielded interface cables must be used with this equipment to maintain compli- ance with FCC regulations in the United States and the Radio communications Act 1992 in Australia/New Zealand as applicable.
  • Page 13: Product Safety Certification

    Product Safety Certification This product is certified by the following Agencies using the Safety standards listed. Agency Standard TUV Rheinland of North America, Inc. UL60950:2000 (USA) Can/CSA-c22.2 No. 60950-00 (Canada) TUV Rheinland Japan Ltd. IEC60950:1999 Safety Notes...
  • Page 14: Regulatory Information

    Regulatory Information CE Mark The CE mark applied to this product symbolizes Xerox's declaration of conformity with the following applicable Directives of the European Union as of the dates indi- cated: January 1, 1995: Council Directive 72/23/EEC amended by Council directive 93/ 68/EEC, approximation of the laws of the member states related to low voltage equipment.
  • Page 15: Environmental Compliance

    Xerox ENERGY STAR equipment is preset at the factory to enter a ”low power” state and/or shut off completely after a specified period of use. These energy-sav- ing features can reduce product energy consumption in half when compared to conventional equipment.
  • Page 16: Product Recycling And Disposal

    Xerox product is part of the program. For more information about Xerox environmental programs, visit www.xerox.com/environment. If you are managing the disposal of your Xerox product, please note that the prod- uct contains lead, mercury and other materials whose disposal may be regulated due to environmental considerations.
  • Page 17: Illegal Copies And Printouts

    Illegal Copies and Printouts Congress, by statute, has forbidden the reproduction of the following subjects under certain circumstances. Penalties of fines or imprisonment may be imposed on those guilty of making such reproductions. Obligations or Securities of the United States Government, such as: Certificates of Indebtedness National Bank Currency Coupons from Bonds...
  • Page 18 been or may be issued under any Act of Congress. Adjusted Compensation Certificates for Veterans of the World Wars. Obligations or Securities of any Foreign Government, Bank, or Corporation. Copyrighted materials, unless permission of the copyright owner has been obtained or the reproduction falls within the "fair use" or library reproduction rights provisions of the copyright law.
  • Page 19 The above list is not all-inclusive, and no liability is assumed for its completeness or accuracy. In case of doubt, consult your attorney. Canada Parliament, by statute, has forbidden the reproduction of the following subjects under certain circumstances. Penalties of fine or imprisonment may be imposed on those guilty of making such reproductions.
  • Page 20: Other Countries

    In case of doubt, contact your legal counsel. Safety Extra Low Voltage Approval These Xerox Digital Copiers/Printers are in compliance with various governmental agencies and national safety regulations. All system ports meet the requirements for Safety Extra Low Voltage (SELV) circuits for connection to customer-owned devices and networks.
  • Page 21: Table Of Contents

    Main Components and Their Function (Rear) ..............6 Switching the Power On and Off .................... 7 Chapter 2 Knowing Your Printer Outline of 6030/6050 Wide Format Print Service ............. 12 Operation from the Printer Control Panel ................22 Operations from Print Services on Web ................
  • Page 22 Power Save Mode ........................168 Chapter 6 Ethernet Print Service (for UNIX) Outline of Ethernet Print Service ..................172 Registering the 6030/6050 Wide Format Printer System ..........173 Printing Using the ftp Command ..................176 Printing Using the lp/lpr Command ...................
  • Page 23 Chapter 10 Paper Heater 10.1 Using the Paper Heater ......................218 Chapter 11 Troubleshooting 11.1 Setup Screen/Printer Control Panel ..................222 11.2 Poor Image Quality ........................ 223 11.3 Other Errors ..........................224 Chapter 12 Clearing Paper Jams 12.1 Paper Jam Display ........................
  • Page 24 Table Of Contents...
  • Page 25: Chapter 1 Main Components And Their Functions

    Chapter Chapter 0 Main Components and Their Functions Chapter 1...
  • Page 26: System Configuration

    The following system configurations and options are available for the Xerox 6030/6050 Wide Format. Xerox 6050 (or 6030) Wide Format Printer This unit is Printer only, refer to the Xerox 6030/6050 Wide Format Printer User Guide for features and usability. Xerox 6030/6050 Wide Format Printer Xerox 6050 (or 6030) Wide Format Copier/Printer This unit features the Copier, Printer and integrated Scanner.
  • Page 27 Xerox 6050 (or 6030) Wide Format Printer with Scan System ® ® This unit features the Copier, Printer, Synergix Scanner and AccXES Controller. Xerox 6030/6050 Wide Format Printer with Scan System Xerox 6050 (or 6030) Wide Format Options You may acquire additional hardware and software options for all units. Contact your Xerox Sales Representative to obtain additional information on options.
  • Page 28: Main Components And Their Functions (Front)

    Main Components and Their Functions (Front) Main Components and Their Functions The combination unit is used for explanatory purposes in this User Guide. Name Function Scanner document table The documents to be scanned are inserted here. Setup screen Used to confirm the settings, such as the print count, and messages relating to the machine status.
  • Page 29: Main Components And Their Functions

    Name Function Media tray (Standard) The dual roll type media tray that feeds roll paper. Scanner power switch Used to switch on/off the power to the scanner. Main Components and Their Functions Name Function Toner supply port The toner is supplied through this port. 1.2 Main Components and Their Functions (Front)
  • Page 30: Main Components And Their Function (Rear)

    Main Components and Their Function (Rear) Main Components and Their Function Name Function Document ejection port The scanned documents are ejected to this port. Power outlet socket Removed from unit. Print ejection port Printed paper is ejected to this port. Remote switch A selector switch that enables the power to both the scanner and the printer to be switched on and off...
  • Page 31: Switching The Power On And Off

    Switching the Power On and Off Both the scanner and the Printer are equipped with their own independent power switches. It is necessary to ensure that the Circuit Breaker Switch is set to ON in order to switch the power of the Printer on and off with the use of its own independent power switch.
  • Page 32 Set the Circuit Breaker on the Printer to ON. Set the Main Power Switch to ON. Main Power Switch Circuit Breaker Chapter 1 Main Components and Their Functions...
  • Page 33: Switching Off The Power

    Switching Off the Power Switch off the power following the steps shown below. Never switch off the power while printing is in progress. Failure to observe this may result in paper jamming in the higher-temperature areas of the machine. [Operation] Set the Main Power Switch to OFF.
  • Page 34 Chapter 1 Main Components and Their Functions...
  • Page 35: Chapter 2 Knowing Your Printer

    Chapter Chapter 0 Knowing Your Printer Chapter 2...
  • Page 36: Outline Of 6030/6050 Wide Format Print Service

    This section provides an outline of the 6030/6050 Wide Format print service. What is the 6030/6050 Wide Format Print Service? The 6030/6050 Wide Format print service is service software that prints out printer data (jobs) transmitted from a client with the use of the 6030/6050 Wide Format printer.
  • Page 37: Printing Procedure

    BT-PlotAssistant (Optional) BT-PlotAssistant is printer support software that operates on Windows machines with the use of a simple GUI. It is possible to print out documents with the 6030/6050 Wide Format printer with this function. Refer to the Xerox 6030/6050 Wide Format BT-Plot Assistant User Guide for details on available functions.
  • Page 38: Print Service Operations

    Print Service Operations The following interface is available to execute the various print service functions. Operations from the printer control panel In addition to printer setup, it is also possible to perform communication interface setup, test printing, log management and other procedures from the printer control panel. Refer to "2.2 Operation from the Printer Control Panel"...
  • Page 39 Operations for Print Services on Web Print Services on Web is web server software pre-installed inside the 6030/6050 Wide Format printer. This enables printer setup, communication interface setup, log management and other procedures to be carried out from a client with the use of a web browser.
  • Page 40: Main Printing Functions

    Main Printing Functions This section provides an overview for main printing functions available with the 6030/ 6050 Wide Format printer. Logical Printers The pen attributes, paper type, number of copies and other printer parameters can be set up from either the printer control panel or Print Services on Web and saved as a logical (or virtual) printer.
  • Page 41 "Automatic" is used under normal circumstances. Specify the paper size manually if all output is to be unified on a single paper size. Refer to the "Output Option" section of "4.5 Logical Printer Settings" for details on available functions (page 84). 2.1 Outline of 6030/6050 Wide Format Print Service...
  • Page 42 Size Mapping When a table determining correspondence between input document sizes and output image size is established beforehand, a document can be enlarged or reduced automatically in accordance with the size mapping table. This function is called "size mapping". Enlarge Input document size Reduce Output image size...
  • Page 43 This performs mirroring (Mirror Image) or 90-degree rotation processing on the output image. Refer to the "Transform" section of "4.5 Logical Printer Settings" for details on available functions (page 95). Mirror image 90-degree rotation Input document Output images 2.1 Outline of 6030/6050 Wide Format Print Service...
  • Page 44: Canceling Jobs

    It is possible to reprint the most recently printed document. The number of copies to be printed can also be specified. Reprinting is not possible with the Xerox 6030 WF or Xerox 6050 WF if a copy operation is performed after print operation.
  • Page 45: Job Recovery

    Refer to the "Setting the Parameters from the Printer Control Panel" section of "3.2 Setting up the System Parameters" for details on job processing after the power is switched on (page 52). 2.1 Outline of 6030/6050 Wide Format Print Service...
  • Page 46: Operation From The Printer Control Panel

    Operation from the Printer Control Panel This section describes the names and functions of the printer control panel parts. <Power Saver> key [Processing] lamp (green) Activates the energy-saving mode. Indicates the printing status. Also cancels the energy-saving mode. Printing in process Energy-saving mode Blinking Receiving print data...
  • Page 47: Basic Printer Control Panel Operations

    Basic Printer Control Panel Operations It is necessary to set the printer in the offline mode in order to set up the various parameters. Press the <Menu> key to switch to the offline mode and display the menu screen. Key Operations The following keys are used on the menu screen.
  • Page 48 Online Mode Ready to print < > key Return to higher level <Menu> key < > key Move to lower level Offline Mode MENU MENU SETUP FILE Specified values: NETWORK/PORT SET SETUP FILE EDIT SETUP FILE Select with the < >...
  • Page 49: Port Setting

    SETUP FILE Sets up logical printers. It is possible to set all parameters required for printing, such as pen width and output paper size. Refer to "5.2 Setting up Logical Printers" for logical printer details and operations (page 129). SYSTEM PARAMETER Sets up the system's management information, such as the system date and hard disk usage conditions.
  • Page 50 Operation Examples This section provides examples of selecting menu items. Ready to print <Menu> key Press the <Menu> key. The machine will enter the offline mode. MENU NETWORK/PORT SET < > key Press the < > key. T h e op e r a t i on m e n u' s t op m e n u w i l l b e MENU displayed.
  • Page 51 < > key Press the < > key to return to an even higher level. MENU PORT SETTING Selecting a value of a feature This section provides an example of setting a value. TRANSFORM Select the menu item that you want to set so that Auto Scale it is displayed on screen.
  • Page 52 Entering Numerals and Characters This section provides examples of entering numerals and characters. Select the menu item that you want to set so that DEF. MULTI PEN Pen No. it is displayed on screen. < > key Press the < >...
  • Page 53: Operations From Print Services On Web

    Operations from Print Services on Print Services on Web is web server software pre-installed on the 6030/6050 Wide Format printer. This enables the following procedures to be carried out from a client with the use of a web browser. •...
  • Page 54 This section explains how to start up and end Print Services on Web. Starting up Web Start up the client, and then the browser. Enter the URL for 6030/6050 Wide Format (http://Home name or IP address) in the browser's address field, and then press the <Enter> key. Ending Web...
  • Page 55 Print Services on Web Page Organization This section explains the various pages contained in Print Services on Web. Main Page This is the first page to be displayed when a connection is established with the Print Services on Web URL. This page is known as the "Main Page". The Main Page allows the following procedures to be carried out.
  • Page 56 Page. The User Main Page allows the following procedures to be carried out. • Click the [Status Update] button to display the most up-to-date status of 6030/6050 Wide Format. • Click the [Job and Log], [Status], or [Print Setup] buttons to display the User Page.
  • Page 57 Page and the user name and password entered. The Administrator Main Page allows the following procedures to be carried out. • Click the [Status Update] button to display the most up-to-date status of 6030/6050. • Click the [Job and Log], [Status], [Print Setup], [Properties], [Tool] or [Change Password] buttons to display the Administrator Page.
  • Page 58 Refer to "4.2 Job Operations" for details on operations (page 72). [Status] tab This tab enables the current status of the 6030/6050 Wide Format, such as the printer status and paper status, to be verified. It is also possible to issue commands to start up the server, receive and terminate jobs, and start print processing from here.
  • Page 59: Online Help

    Online Help Click the [Help] button displayed at the bottom right-hand side of the frame to display the online help. The online help page enables the user to check unclear items relating to Print Services on Web and operation methods. 2.3 Operations from Print Services on Web...
  • Page 60 Chapter 2 Knowing Your Printer...
  • Page 61: Chapter 3 Setup

    Chapter Chapter 0 Setup Chapter 3...
  • Page 62: Setting Up Communication Parameters

    Setting up Communication Parameters It is necessary to connect the 6030/6050 Wide Format printer to the host before it can be used for printing. This section explains the procedures required to set up the connection parameters for the interface that is already installed within the 6030/6050 Wide Format printer.
  • Page 63 TCP/IP The following communication parameters need to be set up. Menu Item Description Default Parser Selects the parser or data format interpreter that is to be used for processing when the input data format has not been specified from [HPGL], [Versatec], [TIFF] and [CALS].
  • Page 64 Serial The following communication parameters need to be set up. Menu Item Description Handshake The handshake method is selected from the following choices. The default setting is [XON/XOFF]. [XON/XOFF] Handshake using the XON/XOFF protocol. [HARDWARE] Handshake using the hardware. [ENQ-ACK] Handshake using the ENQ-ACK protocol.
  • Page 65 Centronics (optional) The following communication parameters need to be set up. Menu Item Description Ack Mode The Ack mode is selected from [MODE0], [MODE1], [MODE2], [MODE3], and [MODE7]. The default setting is [MODE0]. DMA Timeout The timeout value for data input is entered within a range of 1 to 255 seconds.
  • Page 66 SNMP The following communication parameters need to be set up. SNMP can only be set up from Print Services on Web. Menu Item Description SNMP Sets whether to enable SNMP or not. Community Sets the Community string to be imbedded when the client String transmits SNMP packets.
  • Page 67: Operation Procedure

    Setting the Parameters from the Printer Control Panel It is possible to set up the TCP/IP, Serial, Centronics (optional), and VPI (optional) parameters from the printer control panel. The procedures for this are explained below. The changed parameters become valid after the machine has been rebooted. Refer to "2.2 Operation from the Printer Control Panel"...
  • Page 68 TCP/IP PORT SETTING Display [TCP/IP] on the setup item selection TCP/IP screen, and then press the < > key. TCP/IP Select the item that is to be set up with the use of Default Parser the < > and < > keys, and then press the <...
  • Page 69 Adding items to the routing table Static Routing 1. Select [ON] for [Static Routing], and then press the <Set> key. Press the < > key once it has been set. 2. Select [ADD] for the [ROUTING TABLE], ROUTING TABLE and then press the < >...
  • Page 70 Serial PORT SETTING Display [SERIAL] on the setup item selection SERIAL screen, and then press the < > key. SERIAL Select the item that is to be set up with the use of Baud Rate the < > and < > keys, and then press the <...
  • Page 71 VPI (optional) PORT SETTING Display [VPI] on the setup item selection screen, and then press the < > key. Select the item that is to be set up with the use of Job Separation the < > and < > keys, and then press the <...
  • Page 72 An example of the settings printout is shown below. [PLOTTER CONFIGURATION] H/W CONFIG Model DocuWide6050 Software Version = 2.x.00 RAM Total 512 MB Segment Memory 12 MB Work Memory 12 MB Frame Memory 421 MB HardDisk IC35L040AVER07-0 PORT SETTING +- ETHERNET Ethernet Setting = AUTO Ethernet Address =...
  • Page 73: Description Of Each Item

    Description of Each Item The contents of [H/W CONFIG] and [SYSTEM PARAMETER] are shown below. Displayed Item Description Displays the capacity of the memory mounted H/W CONFIG RAM TOTAL on the printer. Displays the capacity of the area in which S E G M E N T intermediate data is stored during print MEMORY...
  • Page 74 Setting the Parameters from Print Services on Web It is possible to set up the TCP/IP, Serial, Centronics (optional), VPI (optional) and SNMP parameters from Print Services on Web. The procedures for this are explained below. • The changed parameters become valid after the machine has been rebooted.
  • Page 75 Set up each of the parameters, and then press the [Apply] button. If a list of the settings is to be printed out, select [Print Settings] from the [System parameters] menu and click the [Print] button situated at the top right- hand corner of the screen.
  • Page 76: Setting Up The System Parameters

    It is possible to set these system parameters with the use of the copier control panel for Xerox 6030 WF and Xerox 6050 WF. If the parameters are set with both the printer control panel and the copier control panel, the values set most recently will be the valid parameters.
  • Page 77: Menu Item Description

    Menu Item Description Low power mode1 Sets the time (1 to 120 minutes) for moving to low power mode 1. Low power mode 1 is the mode that automatically reduces t h e t e m p e r a t u r e o f t h e f u s e r a n d r e s t r i c t s p o w e r consumption.
  • Page 78 Time) can be selected from [10], [30], [60], [90], [120], [180], [240], [300], [360], [420], and [480] (in units of minutes.) • EDMICS is software provided by Fuji Xerox for registering, retrieving, editing and outputting drawings, CAD data and other types of data.
  • Page 79 Operation Procedure MENU Press the < > key with [SYSTEM SYSTEM PARAMETER PARAMETER] displayed. SYSTEM PARAMETER Select the item that is to be set up with the use of Spool in HD the < > and < > keys, and then press the <...
  • Page 80 Setting the Parameters from Print Services on Web It is possible to set up the following system parameters from Print Services on Web. These procedures are performed on the Administrator Page. Menu Item Description Print Services Sets which of the following times should be set as the standard for determining the priority sequence of job output for the same job.
  • Page 81 Setting up print services Select [Print service] from the [System parameters] menu. The print service parameters setup screen will be displayed on the right-hand side of the screen. Select the queuing standard from [QIN_FOPEN] or [QIN_FCLOSE], and then press the [Apply] button. Setting up Extensions Select [Extension] from the [System parameters] menu.
  • Page 82 Setting up the Date Select [Set date] from the [System parameters] menu. The date setup screen will be displayed on the right-hand side of the screen. Enter the date and time, and then press the [Apply] button. Changing User Passwords Select [Display user] from the [User management] menu.
  • Page 83 The password change screen will be displayed on the right-hand side of the screen. Enter the new password twice, and then click the [Apply] button. Adding Users Select [Add user] from the [User management] menu. The screen for adding ftp users will be displayed on the right-hand side of the screen.
  • Page 85: Basic Machine Operations

    Chapter Chapter 0 Basic Machine Operations Chapter 4...
  • Page 86: Basic Machine Operations

    Basic Machine Operations This section explains the following: • Setting up Logical Printers • Selecting Media Types • Using Paper Other Than Default Series Paper • Changing Output Roll Media for an Entire Job • Enlarging and Reducing • Printing Long Documents •...
  • Page 87 Operation Procedure Start up Print Services on Web and display the [Print Setup] tab on the User Page or Administrator Page. Refer to "2.3 Operations from Print Services on Web" for details on starting up Print Services on Web (page 29). Select the format type from [Data format], and then select the logical printer number range from [Detail].
  • Page 88 The logical printer settings will be displayed. Click the [Print] button to print out a list of the logical printer settings. Click the item that is to be set up from the [Detail] menu. The settings for the selected item will be displayed on the right-hand side of the screen.
  • Page 89: Selecting Media Types

    Selecting Media Types The paper type is set with the use of [Media Type] for the logical printers. This parameter can be selected from [Any], [Bond], [Vellum], and [Film]. [Any] is set for this under normal circumstances. Specify the paper type manually if the paper to be used is limited.
  • Page 90: Changing Output Roll Media For An Entire Job

    Changing Output Roll Media for an Entire Job By setting the [Size] on [Output Option] to [AUTO] (either [AUTO], [OTHER], [MIX] or [MIX2]), the output paper is determined in accordance with the logical printer's [Media mapping] table. If a paper mapping table is prepared for each job, it is possible to change the output roll media for each job.
  • Page 91: Enlarging And Reducing

    Enlarging and Reducing It is possible to specify enlargements and reductions with the size mapping table. The size mapping table is a table determining correspondence between the input image size and the output image size beforehand. It enables the user to enlarge/reduce printing according to the table.
  • Page 92: Printing Long Documents

    Printing Long Documents It is possible to set up the method of cutting paper to either the standard A0 format cut (length of 1,189 mm), the standard shape increased in a multiple of integers, or the synchronization cut. This parameter is set up with the use of the [Output Option] function for the logical printers.
  • Page 93: Manual Feed Printing

    Operation Procedure Set [Select Tray] to [Manual]. Transmit printing data to the 6030/6050 Wide Format printer. The following message will be displayed on the printer control panel if no paper has been set in the (MSI) Multi Sheet Inserter/Manual Feed Unit.
  • Page 94: Troubleshooting

    TIFF data will not print properly. Check the compression format of the TIFF data. TIFF data compressed with the LZW format is not supported by 6030/6050 Wide Format and will consequently not be printed out. If the image is printed but either in enlarged or reduced sizes, there are cases where this can be overridden by making sure that resolution for the TIFF data is correctly set in [TIFF Option].
  • Page 95 Required lines will not print out. There are cases where this can be overridden by changing the [White Mode] setting on [Color Option]. The [White Mode] determines whether lines are to be drawn in white or in black when a [White Mode] instruction is received.
  • Page 96: Job Operations

    Job Operations The following operations are possible with the jobs transmitted to 6030/6050 Wide Format when Print Services on Web is used. • Displaying a list of jobs • Canceling and Changing the Priority of Jobs • Managing the Job Logs Displaying a list of jobs This function displays a list of jobs.
  • Page 97 A list of jobs will be displayed on the right-hand side of the screen. To limit the number of logical printers, set up [Logical Printer to be displayed] and [Registration Number], and then click the [Update] button. A list of jobs from the selected logical printers will be displayed. Details Displayed in the List of Jobs This function displays the following contents in the list of jobs.
  • Page 98 Canceling and Changing the Priority of Jobs This function enables jobs to be canceled and the printing priority to be changed. • These procedures can only be performed from the Administrator Page. • Jobs for which the print process has been completed cannot be canceled or have their priority changed.
  • Page 99 Click the [Change] button located on the right-hand side of the job. The following screen will be displayed. Click the [Cancel Job] - [Execute] button to cancel the job or select [High], [Normal] or [Low] from the [Change priority] drop down menu, and click the [Set] button.
  • Page 100: Job Log

    Managing the Job Logs This function allows the various histories (logs) to be printed and deleted. There are two types of logs available: Job Log, and Error Log. It is only possible to display a list of job histories on the User Page. All other operations can only be carried out on the Administrator Page.
  • Page 101 Printing Logs Enter the date of the logs to be printed in [Printing range], and then click the [Print] button. Deleting Logs Click the [Change settings] button. The change log setting screen will be displayed. • Click the [Delete] button to delete a log. •...
  • Page 102: Error Log

    Error Log This records detailed information on the errors that occurred during job processing. Operation Procedure Start up Print Services on Web and display the [Job and Log] tab on the User Page or Administrator Page. Select [Error Log] from the [Log list] menu. A list of logs will be displayed on the right-hand side of the screen.
  • Page 103: Printer Operations

    Printer Operations The following operations are possible with the 6030/6050 Wide Format printer when Print Services on Web is used. • Displaying the Printer Status • Starting up and Suspending Received Jobs, Printing, and the Server Displaying the Printer Status This function displays the status of the 6030/6050 Wide Format printer.
  • Page 104 Displays the optional finisher attached to the printer. Processing data formats Displays the data formats that can be processed. Software version Displays the version of the 6030/6050 Wide Format printer's software. Engine parameter Displays the status of the following parameter settings.
  • Page 105 IOT_COM_ERR A communication error has occurred with the printer. Switch off the power of the printer, and then switch it on again. If the problem is not recovered, contact your Xerox Service Representative. IOT_NO_PAPER The printer's paper has run out. Place more paper in the tray that is empty.
  • Page 106 Starting up and Suspending Received Jobs, Printing, and the Server This function enables the following procedures to be carried out. • Suspending job receipt Jobs are no longer received from the client. • Starting up job receipt Starts the receipt of jobs. •...
  • Page 107: Test Printing

    Test Printing This function prints out test data in order to check the operations of the printer. These procedures can only be performed from the Administrator Page. It is also possible to perform test printing from the printer control panel. Refer to "5.3 Test Printing"...
  • Page 108: Logical Printer Settings

    Logical Printer Settings This section provides detailed explanations on the logical printer settings.The settings may be accessed by using the Printer Control Panel or by accessing Print Services on Web. Logical printer The following parameters can be set for logical printers. However, the items that can be set will differ in accordance with the data format.
  • Page 109 Relevant Menu Item Description Format Drawing Rotation Sets the rotation direction for rotation printing. Direction Skip Command Enables and disables the PS command. HPGL EOP Command Enables and disables the EOP command. HPGL Color Option Enables and disables the white line function. HPGL, Versatec Media Exit...
  • Page 110: Media Series

    Media Series Sets the paper groups for the input, output and printing paper. It is also possible to set different groups for each of these. Settings The settings for this function are as follows. All of the default settings are [ISO A]. Menu Item Description Input size...
  • Page 111: Define Single Pen

    Define Single Pen Sets the width, color and other pen attributes for HPGL data. These settings are only valid with HPGL data. Settings The settings for this function are as follows. Menu Item Description Pen No. Sets the pen number within a range of 0 to 98. Width Sets the line width within a range of 0 to 511.
  • Page 112 End style SQUARE The normal method of ending lines. ROUND Rounds off both ends of the line with a half radius of the line Line width width. Half the line width Half the line width EXTEND Adds half of the line width in length to both ends of the line. Line width Half the line width Half the line width...
  • Page 113: Define Multi Pen

    Define Multi Pen Sets the line width, color and other pen attributes for HPGL data for multiple pens. The same parameters will be set for all other pen numbers within the range of specification. These settings are only valid with HPGL data. Settings The settings for this function are as follows.
  • Page 114 Versatec Pen Style Sets the pen specifications for VCGL data. These settings are only valid with Versatec VCGL data. Settings The settings for this function are as follows. Menu Item Description Joint style Sets joint processing for lines to [UNJOINT], [BEVEL], [MITER] or [ROUND].
  • Page 115 Versatec Width Sets the width of the VCGL data pen. These settings are only valid with Versatec VCGL data. Settings The settings for this function are as follows. Menu Item Description Width Sets the line width within a range of 0 to 511. 1 = 0.0635 mm.
  • Page 116 Versatec Def. Multi Pen Sets the pen attributes for VRF data for multiple pens. The same parameters will be set for all other pen numbers within the range of specification. These settings are only valid with Versatec VRF data. Settings The settings for this function are as follows.
  • Page 117: Pen Option

    Emulation Selects the processing language for the HPGL format. These settings are only valid with HPGL data. Settings The settings for this function are as follows. Menu Item Description Emulation Sets the processing language from [HPGL] or [HPGL2]. The default setting is [HPGL]. Pen Option Sets whether or not to change the ratio of the pen thickness in accordance with enlargement/reduction rates when enlarging or reducing for printing purposes.
  • Page 118: Tiff Option

    TIFF Option Sets the sorting and output sequence, and the resolution priority for TIFF data. These settings are only valid with TIFF data. Settings The settings for this function are as follows. Menu Item Description Sort Mode Sets whether or not to sort the data for output purposes. The default setting is [OFF].
  • Page 119 Transform Sets automatic enlargement/reduction, mirror processing and 90-degree rotation. • Auto Scale Input image Output image • Mirror Image Input image Output image • 90 - degree Rotation Input image Output image 4.5 Logical Printer Settings...
  • Page 120 Settings The settings for this function are as follows. Menu Item Description Auto Scale Sets whether or not to automatically enlarge or reduce sizes when the input size and output size are different. The default setting is [ON]. [ON] Automatically enlarges or reduces the size of the image to match the output size.
  • Page 121: Plot Area

    Plot Area Enables the print range (plot area) to be specified from the input image. The plot area can be specified to lay out the image in the center of the output paper (Auto Layout) or offset it (Set Offset Value). Any part of the image that overlaps the margin when offset has been specified will be cut.
  • Page 122 Settings The settings for this function are as follows. The area mode cannot be set for TIFF and CALS data. Only the auto layout function can be set. Menu Item Description Area Mode Sets the range to be printed at [ADAPTED], [FIXED], [IP AREA], [IW AREA], [RASTER] or [FIRST].
  • Page 123 Descriptions of Area Mode The various area modes are described below. ADAPTED The data range of the input image is set as the print range. Fig.1 FIXED (HP-GL) The range that encloses the maximum coordinate of the input image and the coordinates that represent the starting point of that coordinate is set as the print range.
  • Page 124 Fig.3. (IP AREA and IW AREA) The area specified with the [IP Command] or [IW Command]. Input image (0,0) Output image Offset Auto Layout: [YES] Auto Layout: [NO] Fig.4. (FIRST) (0,0) Output image Offset Auto Layout: [YES] Auto Layout: [NO] Fig.5.
  • Page 125: Message Option

    Message Option Sets whether or not to print error messages, label messages and date messages. The size of the characters used in the messages are fixed at a height of 2 mm regardless of whether the document is enlarged or reduced. 5 mm Top right Top left...
  • Page 126: Setting Example

    Media Margin Sets the top, bottom, left and right margin values for determining input sizes. + values represent margins outside of the paper size, and – values represent margins inside the paper size. The size that includes (excludes) these margins is established as the input judgment size.
  • Page 127 Size and Media Mapping It is possible to enlarge or reduce standard size images and user-defined images to fit standard and user-defined output sizes with 6030/6050 Wide Format. This function is known as "Size Mapping". It is also possible to specify which roll media is to be used for actual printing in accordance with the output size.
  • Page 128 Settings The settings for this function are as follows. Menu Item Description Auto Mapping Sets whether the automatic mapping function is to be enabled or not. The output paper size that best matches the output image size will be determined automatically when this function is set to [Enable].
  • Page 129 Size mapping is applied to the image with an input size of A3, which is then enlarged to an A2 output size (enlarged by 141.4%). Media mapping is applied as the output size is A2, and the image is printed on the A1 roll media (rotated by 90 degrees and output).
  • Page 130: Split Drawing

    Split Drawing It is possible to fragment images that exceed 1,189 mm in length for output purposes. It is also possible to add marks for positioning purposes on each fragment. A maximum of 30 fragmentations are possible. Fragment length Fragment length Settings The settings for this function are as follows.
  • Page 131 Priority Sets the priority for printing. This function is used to increase the priority of jobs to print them out first when the job queue is congested. Settings The settings for this function are as follows. Menu Item Description PRIORITY Sets either of the following as the printing priority.
  • Page 132: Skip Command

    Skip Command Enables and disables the PS command. These settings are only valid with HPGL data. Settings The settings for this function are as follows. Menu Item Description PS Command [OFF] Enables the PS command. [ON] Disables the PS command. The default setting is [ON].
  • Page 133: Color Option

    Color Option Sets the drawing color from specified density to black when color command other than black is specified. This setting is only valid for HPGL and Versatec data. Settings The settings for this function are as follows. Menu Item Description White Mode Sets the drawing method when a color other than black is...
  • Page 134: Select Tray

    Select Tray Sets whether the paper is to be fed automatically from the feed trays or from the manual feed tray. The priority sequence for when automatic selection from the feed tray has been specified is [Roll 1], [Roll 2], [Roll 3], and [Roll 4] in this order. The optional (MSI) Multi Sheet Inserter/Manual Feed Unit is required for manual feeding.
  • Page 135: Input Option

    Input Option Sets the input image size. The following two judgment methods are available for input image size. • Automatic (AUTO) Calculates the coordinates of the input image and automatically determines the nearest size. • Specify Size Enables the paper size of the input image to be entered directly. The paper size can be selected from standard sizes and user-defined sizes.
  • Page 136: Output Option

    Output Option Sets the output size. The following two judgment methods are available for output image size. • Automatic (AUTO, OTHER, MIX, MIX2) Determines the most suitable output size based on the input size and the size mapping table. It also determines the paper or roll media size to use for actual printing in accordance with the output size and the paper mapping table (or automatically.) •...
  • Page 137 Menu Item Description Number of Sets the number of copies to be printed consecutively from a range of Joints 0 to 99 when [Size] has been specified. The default setting is [0]. A value that subtracts 1 from the length of the standard size will be set for [Connect].
  • Page 138: Media Type

    Media Type Sets the paper type. This setting is valid when a different type of paper of the same size is set in the printer. [ANY] is set for this under normal circumstances. When the paper type specification command is already set in the data from the host, the host command has priority.
  • Page 139 Size Recognition Priority Sets whether images that are within the A0 size (length:1,189 mm) but that exceed the standard size are to be output on one size larger standard size paper, or if they are to be output on a standard size that has been increased by a multiple of whole numbers. This setting is useful when all images are to be output on the same size of standard output paper or on a standard size that has been increased by a multiple of whole numbers.
  • Page 140 Chapter 4 Basic Machine Operations...
  • Page 141: Chapter 5 Setup Using The Printer Control Panel

    Chapter Chapter 0 Setup Using the Printer Control Panel Chapter 5...
  • Page 142: List Of Menu Items

    List of Menu Items Press [Menu] to take offline. A list of the printer control panel menu items are provided below. The top level begins with Network/Port Set or Print Setup. The menu options in the table below preceded by the [ ] mark represent the value settings.
  • Page 143 Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 S Y S T E M Set Date Set Date PARAMETER YY/MM/DD hh: mm Spool in HD Spool in HD OVERFLOWELEMENT ALWAYS AUTO ROLL Roll Tray Roll Tray Tray Roll Tray Roll SPA PAPER WIDTH...
  • Page 144 Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 P O RT TCP/IP Ethernet Setting Ethernet Setting SETTING AUTO 10BASE_T 100BASE_T Default Parser Default Parser HPGL TIFF CALS Versatec IP Address IP Address xxx.xxx.xxx.xxx MASK Value MASK Value xxx.xxx.xxx.xxx E-Net Address E-Net Address...
  • Page 145 Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 P O RT SERIAL Handshake Handshake SETTING XON/XOFF HARDWARE ENQ-ACK SOFTWARE (ENQ-ACK and SOFTWARE only with HPGL) Baud Rate Baud Rate 1200 2400 4800 9600 19200 Parity Parity NONE EVEN Data Bit...
  • Page 146 Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 P O RT Report Offline Report Offline SETTING (optional) EOP Timeout EOP Timeout Timeout Value NO_TIMEOUT 1 to 255 sec TIMEOUT Job Separation Job Separation PRINT CONFIG SET: to Print. TEST PLOT Plot Size Plot Size...
  • Page 147 Supplementary Table (Continued from [Setting]) Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 MEDIA SERIES Input Input ARCH JIS B ANSI ISO A Output Output ARCH JIS B ANSI ISO A Media Media ARCH JIS B ANSI ISO A DEF.SINGLE PEN...
  • Page 148 Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 PEN STYLE Jointstyle Endstyle (Versatec only) SQUARE ROUND EXTEND TRIANGLE Endstyle Jointstyle UNJOINT BEVEL MITER ROUND Dashstyle Dashstyle NO_WRAP WRAP DEF.SINGLE PEN Pen No. Pen No. Color Color (Versatec only) 0 to 31 BLACK...
  • Page 149 Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 TRANSFORM Auto Scale Auto Scale Mirror Image Mirror Image Rotate 90 Rotate 90 ( O n l y w h e n [ I n p ut Link Count] has been set to anything other than [AUTO].) PLOT AREA...
  • Page 150 Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 SIZE/MEDIA MAP. Input Input Mapping Mapping Various paper sizes Various paper sizes Media Media Media AUTO Various paper sizes MANUAL SPLIT SPLIT Fragment Length Fragment Length 1189 to 15000 Page No Page No Margin...
  • Page 151 Level 5 Level 6 Level 7 Level 8 Level 9 Level 10 SELECT TRAY Tray Tray AUTO MANUAL Priority Priority CONTROLLER PRINTED COPY Copies Copies 1 to 99 Priority Priority (Versatec only) COMMAND MENU INPUT OPTION Size Size Connect Connect AUTO 0 to 99 Various paper sizes...
  • Page 152 The table below lists the printer control panel menu levels from the Print Setup top level. Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 PRINT SETUP MEDIA MEDIA/Roll 1,2,3,4 & Type MEDIA Media Roll1 Bypass BOND Media Roll2 Type Media Roll3...
  • Page 153: Setting Up Logical Printers

    Setting up Logical Printers The following operations related to logical printers are set up from the printer control panel. • Setting up Logical Printers • Setting up the Default Logical Printer • Printing out a List of Settings Parameters for Logical Printer The following parameters can be set for logical printers.
  • Page 154 Data Parameter Description Relevant Section Format MEDIA MARGIN Sets the top, bottom, left and right margin values. Media Margin SIZE/MEDIA MAP. Sets up the size mapping and paper mapping S i z e a n d M e d i a parameters.
  • Page 155 Setting up Logical Printers One hundred types of logical printers are available for each data format and it is possible to set each of these individually. The formats can be chosen from [HPGL], [Versatec], [TIFF] and [CALS]. The file numbers (logical printer numbers) can be specified within a range of 0 to 99. Refer to "2.2 Operation from the Printer Control Panel"...
  • Page 156 HPGL Versatec TIFF CALS MEDIA SERIES MEDIA SERIES MEDIA SERIES MEDIA SERIES DEF.SINGLE PEN PEN WIDTH TIFF OPTION CALS OPTION DEF.MULTI PEN PEN STYLE TRANSFORM TRANSFORM EMULATION DEF. SINGLE PEN PLOT AREA PLOT AREA PEN OPTION DEF. MULTI PEN MESSAGE OPTION MESSAGE OPTION TRANSFORM PEN OPTION...
  • Page 157 MEDIA SERIES EDIT HPGL Display [MEDIA SERIES] on the setup item MEDIA SERIES selection screen, and then press the < > key. MEDIA SERIES Select the item that is to be set up with the use of Input the < > and < > keys, and then press the <...
  • Page 158 DEF.MULTI PEN (HPGL only) EDIT HPGL Display [DEF.MULTI PEN] on the setup item DEF. MULTI PEN selection screen, and then press the < > key. DEF. MULTI PEN Press the < > key. Pen No. From – To Select the starting number and ending number of 00 –...
  • Page 159 Width Select the pen width with the use of the < > and < > keys, and then press the <Set> key. PEN STYLE (Versatec only) EDIT Versatec Display [PEN STYLE] on the setup item PEN STYLE selection screen, and then press the < >...
  • Page 160 Pen No. 05 Select the item that is to be set up with the use of Endstyle the < > and < > keys, and then press the < > key. The [Color] and [Endstyle] parameters will be displayed in that order. Endstyle Select the parameters with the use of the <...
  • Page 161 EDIT HPGL Display [EMULATION] on the setup item EMULATION selection screen, and then press the < > key. EMULATION Press the < > key. Emulation Emulation Select the HPGL processing language with the HPGL use of the < > and < > keys, and then press the <Set>...
  • Page 162 Sort Mode Select the parameters with the use of the < > and < > keys, and then press the <Set> key. When [MENU] has been selected with [DPI] MENU 1. Press the < > key immediately after pressing the <Set> key. 2.
  • Page 163 CALS OPTION (CALS only) EDIT CALS Display [CALS OPTION] on the setup item selection screen, and then press the < > key. CALS OPTION Press the < > key. Enable Rotation Enable Rotation Select whether or not to enable the [ROTATE] command with the use of the <...
  • Page 164 TRANSFORM EDIT HPGL Display [TRANSFORM] on the setup item TRANSFORM selection screen, and then press the < > key. TRANSFORM Select the item that is to be set up with the use of Auto Scale the < > and < > keys, and then press the <...
  • Page 165 2. Select the paper size with the use of the < > Size and < > keys, and then press the <Set> key. Press the < > key once it has been set. 3. Select either [OffsetX] or [OffsetY] with the Set Offset Value use of the <...
  • Page 166 MESSAGE OPTION EDIT HPGL Press the < > key with [MESSAGE OPTION] MESSAGE OPTION displayed on the setup item selection screen. MESSAGE OPTION Select the item that is to be set up with the use of Error Message the < > and < > keys, and then press the <...
  • Page 167 MEDIA MARGIN EDIT HPGL Display [MEDIA MARGIN] on the setup item MEDIA MARGIN selection screen, and then press the < > key. MEDIA MARGIN Select either [MarginX] or [MarginY] with the Margin X use of the < > and < > keys, and then press the <...
  • Page 168 When [Mapping] has been selected Mapping Select the paper size with the use of the < > and < > keys, and then press the <Set> key. When [Media] has been selected Media MANUAL 1. Select either [Auto] or [MANUAL], and then press the <Set>...
  • Page 169 W he n [ O N ] h a s be en se le c t e d f o r Margin [Margin] 1. Press the < > key immediately after pressing the <Set> key. 2. Select the margin with the use of the < > and Set Margin Len.
  • Page 170 SKIP COMMAND (HPGL only) EDIT HPGL Display [SKIP COMMAND] on the setup item SKIP COMMAND selection screen, and then press the < > key. SKIP COMMAND Press the < > key. PS Command PS command Select whether or not to disable the PS command with the use of the <...
  • Page 171 COLOR OPTION (HPGL and Versatec only) EDIT HPGL Display [COLOR OPTION] on the setup item COLOR OPTION selection screen, and then press the < > key. COLOR OPTION Press the < > key. White Mode White Mode Select whether or not to enable the White line function with the use of the <...
  • Page 172 PRINTED COPY EDIT HPGL Display [PRINTED COPY] on the setup item PRINTED COPY selection screen, and then press the < > key. PRINTED COPY Select the item that is to be set up with the use of Copies the < > and < > keys, and then press the <...
  • Page 173 OUTPUT OPTION EDIT HPGL Display [OUTPUT OPTION] on the setup item OUTPUT OPTION selection screen, and then press the < > key. OUTPUT OPTION Press the < > key. Size Size Select either [AUTO], [OTHER], [MIX], [MIX2] or the various paper sizes with the use of the <...
  • Page 174 MEDIA TYPE EDIT HPGL Display [MEDIA TYPE] on the setup item MEDIA TYPE selection screen, and then press the < > key. MEDIA TYPE Press the < > key. Type Type Select the relevant paper type with the use of the Vellum <...
  • Page 175 SIZE PRIORITY EDIT HPGL Display [SIZE PRIORITY] on the setup item SIZE PRIORITY selection screen, and then press the < > key. SIZE PRIORITY Press the < > key. Priority Priority Select the size priority mode with the use of the LONG <...
  • Page 176 Setting up the Default Logical Printer The following procedure sets up the logical printer that is to be used as the default. Operation Procedure MENU Press the < > key with [SETUP FILE] SETUP FILE displayed on the parameter selection screen. SETUP FILE Select [DEF.
  • Page 177 Printing out a List of Settings This function prints out a list of the settings established for the logical printers. Operation Procedure MENU Press the < > key with [SETUP FILE] SETUP FILE displayed on the parameter selection screen. SETUP FILE Select [PRINT SETUP] with the <...
  • Page 178: Test Printing

    Test Printing This function prints out test data in order to printer operations to be verified. The paper size can be selected from between A0 and A4. Refer to "2.2 Operation from the Printer Control Panel" for detailed instructions on printer control panel operations (page 22).
  • Page 179: Managing The Various Logs

    Managing the Various Logs The following two types of logs are available. It is possible to print and delete these logs. • JOB LOG • ERROR LOG Refer to "2.2 Operation from the Printer Control Panel" for detailed instructions on printer control panel operations (page 22).
  • Page 180: Auto Mode

    2. Select either [ON] or [OFF] with the use of Auto Mode the < > and < > keys when [Auto Mode] has been specified, and then press the <Set> key. When automatic printing is set to [ON], the processed jobs will be automatically p r i n t e d w h e n 5 1 p a g e s h a v e accumulated.
  • Page 181 Managing the Error Log This section explains the procedures for managing the error log. Operation Procedure MENU Press the < > key with [JOB LOGGING] JOB LOGGING displayed. JOB LOGGING Display the [ERROR LOG] with the use of the ERROR LOG <...
  • Page 182 Press the <Set> key when [SET:to Clear.] is SET : to Clear. displayed. The error log will be deleted accordingly. Example of a Error Log List [ErrorLog : Page 1] [Xerox 6050WF Version 2.2.XX] JobNo Data&Time Task Name ErrNo ErrorLevel Error Log...
  • Page 183: Reprinting

    It is possible to specify the number of copies to be printed within a range of 1 to 99. Reprinting is not possible with the Xerox 6030 WF or Xerox 6050 WF if a copy operation is performed after a print operation.
  • Page 184: Meter Confirmation

    Meter Confirmation It is possible to display meters on the printer control panel for confirmation purposes. Values with a maximum of nine digits can be displayed. Menu Item Description METER 1 The total area in units of square feet of paper printed up until now. (unit: ft METER 2 The total length printed up until now.
  • Page 185: Operations From The Printer Control Panel

    Operations from the Printer Control Panel This section explains the main components and their functions of the printer control panel. <Power Saver> key [Processing] lamp (green) Activates the energy-saving mode. Indicates the printing status. Also cancels the energy-saving mode. Printing in process Energy-saving mode Blinking Receiving print data activated.
  • Page 186: Menu Hierarchy

    Basic Operations of Printer Control Panel It is necessary to set the printer in the offline mode in order to set up the various parameters. Press the <Menu> key to switch to the offline mode and display the menu screen. Menu Hierarchy The operation menus have the following menu hierarchy.
  • Page 187 Operation Examples This section provides examples of selecting menu items. Ready to print <Menu> key Press the <Menu> key. The top menu will be displayed. MENU NETWORK/PORT SET < > < > key Press the < > key. The top menus will be displayed in sequence. MENU PRINT SETUP The previous menu will be displayed if...
  • Page 188 Selecting Specified Values This section provides examples of setting a specified value. Media The menu items will be displayed. Roll1 < > key Press the < > key. The specified value will be displayed. Media / Roll1 Type : Bond <...
  • Page 189: Printer Settings

    Printer Settings This section explains the items that can be set up on the printer control panel. Menu Item Description Media Sets up the type, size, weight and other parameters of the media that is to be loaded into the machine for each of the rolls.
  • Page 190 Media Ensure that these parameters are set up when new paper is to be loaded into the machine and when the media type and size is to be changed. Media Type Roll1 Bond Roll2 Vellum Roll3 Film Roll4 Bypass Weight Light Bond Heavy...
  • Page 191 The media sizes for which [Group] can been specified. A4 (210 × 297 mm) Media set to [ISOA] A3 (297 × 410 mm) A3 roll (297 mm wide) A2 (420 × 594 mm) A2 roll (420 mm wide) A1 (594 × 841 mm) A1 roll (594 mm wide) A0 (841 ×...
  • Page 192: Power Save Mode

    <Power Saver> key on the printer control panel is pressed. The power save modes can also be set up from the copier control panel with Xerox 6030 Wide Format and Xerox 6050 Wide Format. The most recently set parameters are used when these modes have been set up on both the printer and the copier control panels.
  • Page 193 < > key Select either [Low power mode 1], [Low power SYSTEM PARAMETER mode 2] or [Sleep Mode] with the use of the Low power mode1 < > key. < > key Press the < > key. Low power mode1 <...
  • Page 194 Chapter 5 Setup Using the Printer Control Panel...
  • Page 195: Chapter 6 Ethernet Print Service (For Unix)

    Chapter Chapter 0 Ethernet Print Service (for UNIX) Chapter 6...
  • Page 196: Outline Of Ethernet Print Service

    Outline of Ethernet Print Service Use the ftp command or the lpr command for printing from the 6030/6050 Wide Format when running on UNIX. This section explains how to set up the ftp and lpr commands and their formats. The file to be printed should be in a data format that the 6030/6050 Wide Format supports.
  • Page 197: Registering The 6030/6050 Wide Format Printer System

    When a name service besides NIS and DNS is used, the IP address and host name must be registered in the database used to transfer the file on the client side. SunOS 5.X In the case of SunOS 5.X, register the IP address and host name of the 6030/6050 Wide Format printer in the /etc/hosts file that defines the printers connected to the network.
  • Page 198: Registering The Remote Printer

    Registration information depends on the system, but logical device names on the workstation must correspond with logical printers on the 6030/6050 Wide Format printer system. Refer to the "Main Printing Functions" (page 16) section in "2.1 Outline of 6030/6050 Wide Format Print Service" for logical printers. SunOS 5.X For SunOS 5.X, register the remote printer using the lpadmin command.
  • Page 199 • Editing the /etc/qconfig file In the example below, the 6030/6050 Wide Format printer system called [oklahoma] is registered in the [/etc/qconfig] file. In this setting, when you send a file to a printer device called [plt10h] or [plt20h], the file is sent to [oklahoma].
  • Page 200: Printing Using The Ftp Command

    Connected to 6050WF. 220 6050 Wide Format FTP server ready Name (6050WF:ftpusr): Log on to 6030/6050 Wide Format. Enter a user name (example: ftpusr) pre- registered in 6030/6050 Wide Format. You are prompted to enter a password. Name (6050WF:ftpusr): ftpusr...
  • Page 201 Enter the password of the user logged in at Step If the user information registered in 6030/6050 Wide Format matches the logged- in user password, the login acceptance message is displayed. Password: 230 User logged in ftp> The password of the user (ftpusr) is ftpusr at shipping.
  • Page 202 Specify the end. Enter the bye subcommand. A message indicating that ftp command has completed will be displayed. ftp> bye 221 Bye...see you later Chapter 6 Ethernet Print Service (for UNIX)
  • Page 203: Other Subcommands

    Displays directory, will display logical printers set from the control panel. If nothing is specified in 6030/6050 Wide Format, only the logical printer at address 00 is displayed. Displays directory, will display logical printers set from the console panel.
  • Page 204: Message List

    Message List This section explains messages that may be displayed during printing using the ftp command. Can't build data connection Status: Cannot establish connection for data transfer. Action: Wait a few moments and try again. Can't create control file, please try later Status: Cannot create a control file using the STOR command.
  • Page 205 Data connection error Status: A data connection error occurred during file transfer. Action: Establish connection and transfer the file again. Directory non existent or syntax error Status: A non-existing directory (logical printer) is specified. Action: Specify the correct directory (logical printer). Error in input file Status: An error occurred in an output file during transfer.
  • Page 206 Status: Cannot accept data transfer because the system is overloaded. Action: Check the system for a media-out or media jam error. Wait for some time and try again. If the error occurs frequently, restart 6030/6050 Wide Format. Local resource failure: ReceiveCmplt status Status: Failed to transfer the file.
  • Page 207 Login failed Status: The user name and password do not match. Action: Log in again with the correct user name and password. No file found or invalid directory or permission problem Status: Failed to open the directory by the LIST command. Action: Wait for some time and transfer the command again.
  • Page 208 Unimplemented TYPE x Status: Transfer by the non-supported type was instructed. Action: Specify [ Image (Binary) ] or [ ASCII ] with the TYPE command. User "xx" is not existed, need account for login Status: Logged in with a user name not registered. Action: Log in with a registered user name.
  • Page 209: Printing Using The Lp/Lpr Command

    Printing Using the lp/lpr Command Details of each command are explained. Bold characters represent input character strings in each example. Printing (lpr Command) This section explains the printing procedure using the lpr command. Format lpr [-P<Logical Printer Name>] [-#<Copy Count>] [-s] <File Name> -P<Logical Printer Name>...
  • Page 210 Example 1:Outputting one copy of the [drawa.hpgl] file to the logical printer [plt00h]. % lpr -Pplt00h drawa.hpgl Example 2:Outputting two copies of the [drawb.hpgl] and [drawc.hpgl] files each to the logical printer plt00h. % lpr -Pplt00h -#2 drawb.hpgl drawc.hpgl Example 3:Outputting one copy of the [drawd.hpgl] file to the logical printer [plt01h]. % lpr -Pplt01h drawd.hpgl Example 4:Outputting one copy of the [drawe.hpgl] and drawf.hpgl files each to the logical printer [plt02h].
  • Page 211 Printing (lp Command) (for SunOS 5.x) This section explains the printing procedure using the lp command. Format lp [-d <Logical Printer Name>] [-n <Copy Count>] [-c] <File Name> lp [-d <Logical Printer Name> Data is output to the specified printer. -n <Copy Count>...
  • Page 212 % lpq -Pplt00h no entries Example 2:Displaying the status of a file transferred to the logical printer [plt01h]. When transfer of the [drawd.hpgl] file to the 6030/6050 Wide Format is already completed, the following message will be displayed. % lpq -Pplt01h Job ID Sent By Status Prior.
  • Page 213 6030/6050 Wide Format. cosmos: sending to oklahoma Rank Owner Job Files Total Size indicates the client status. The job ID for client and the job ID for the 6030/6050 Wide Format are assigned separately. 6.4 Printing Using the lp/lpr Command...
  • Page 214 Specify a job ID to cancel its printing. The status display command [ lpq ] displays <Job ID> job IDs. If this is omitted, every possible print job is canceled. Job IDs on the 6030/6050 Wide Format side and the client side are allocated separately. Examples of use Example 1:Displaying the status of the logical printer [plt01h] and canceling the printing of job ID [124].
  • Page 215 Example 2:Displaying the status of the logical printer [plt01h] and canceling the printing of job ID [123] This print job cannot be canceled because it is already in progress. % lpq -Pplt01h Job ID Sent By Status Prior. Document Name Size(KB) williams Printing...
  • Page 216 Example 4:Displaying the status of the logical printer [plt01h] and canceling the printing of job ID [416] in the client queue If the file transfer to 6030/6050 Wide Format is completed before the job in the client queue is canceled, the print job cannot be canceled. 6030/6050 Wide Format displays the print status, checks the job IDs of the logical printer, and cancels the print job again.
  • Page 217 Message List This section explains messages that may be displayed during printing using the lpr command. These messages depend on the system because they are output from the client workstation. Cannot create /usr/spool/pltXXX/.seq Status: The lpd daemon on the client failed to create a control file. Action: Check the spool directory.
  • Page 218 PLTXX can not dequeue Status: Failed to delete a job from the logical printer PLTXX on the print service side. Action: Check by the lpq command whether the specified job has already changed from the wait status in the queue to the processing status. connection busy Status: Failed to establish connection for data transfer.
  • Page 219: Chapter 7 Leading Edge Cutting Methods

    Chapter Chapter 0 Leading Edge Cutting Methods Chapter 7...
  • Page 220: Cutting Leading Edge

    Cutting Leading Edge The leading edge of the media is cut before use after paper jams have been recovered, when the media is replaced, and when the leading edge of the paper has become damaged. There are two methods available for cutting the leading edge. •...
  • Page 221: Automatic Cut

    Automatic Cut Operation Procedure Select [Media] from the menu displayed on the Print Settings printer control panel. Media < > key Press the < > key. The level from which the desired media is to be Media selected will be displayed. Roll1 <...
  • Page 222: Manual Cut

    Manual Cut For the roll at the front [Operations] Open the media tray. Pull the lever to open the tray cover. Lever Rotate the roll paper until the leading edge is gripped by the roller. Chapter 7 Leading Edge Cutting Methods...
  • Page 223 Rotate the knob until the media's leading edge protrudes from the tray outlet. Operate the cutter to cut the paper. CAUTION: Ensure that you utilize the cutter handle and that you do not slide your fingers along the metal cutting bar, as it is sharp.
  • Page 224 Close the media tray. For the roll at the rear [Operations] Open the media tray. Rotate the roll paper until the leading edge is gripped by the roller. Chapter 7 Leading Edge Cutting Methods...
  • Page 225 Pull the lever to open the tray cover. Rotate the knob until the media's leading edge protrudes from the tray outlet. Hold the paper against the baffle and rotate the knob as the paper passes through the tray outlet as shown in the illustration. Hold the paper taut while operating the cutter to cut the paper.
  • Page 226 Return the media to its original location by rotating the roll of media until the leading edge of the paper can be seen in the window and the media is taut on the roll. Close the media tray. Chapter 7 Leading Edge Cutting Methods...
  • Page 227: Chapter 8 Replacing Paper

    Chapter Chapter 0 Replacing Paper Chapter 8...
  • Page 228: Display When Paper Runs Out

    Display When Paper Runs Out A message stating "Replace xxx media." will be displayed on the setup screen if there is no media loaded in position for printing purposes. The media size displayed on the control panel will be turned off when there is no paper in the machine.
  • Page 229: Replacing Roll Paper

    Replacing Roll Paper Two rolls of paper can be set into each of the media trays. Refer to the instructions provided in Chapter 5 and set up the paper parameters accordingly after the rolls have been replaced. [Operations] Open the media tray. Remove the shaft containing the roll paper that is to be replaced.
  • Page 230 There is an area at the front of the tray on which the roll paper can be placed. While pulling the lever situated in the end of the roll paper shaft, align the roll paper with the paper size marks on the shaft and set the roll in place.
  • Page 231 Gently close the media tray until it is firmly in position as far back as it can go. The LED on the front of the media tray will be illuminated, and the roll paper will be automatically set in place. Set up the media parameters on the printer control panel.
  • Page 232: Drawer Media Size Indicators

    Drawer Media Size Indicators The media size indicators are pieces of paper used so that the user may identify the media that is placed in each of the drawers. This is visible on the right hand side of the drawers. The instructions on usage are provided on the next page. The following four types are available.
  • Page 233: Inserting Media Size Sheets

    Inserting media size sheets Open the tray for which the paper size has been changed. Remove the media size sheet. Fold the sheet so that the size loaded is displayed. Insert the media size sheet. 8.3 Drawer Media Size Indicators...
  • Page 234 Gently close the media tray until it is firmly in position as far back as it can go. Chapter 8 Replacing Paper...
  • Page 235: Loading Media Manually

    Loading Media Manually [Operations] Adjust the (MSI) Multi Sheet Inserter/Manual Feed Unit's side guide to fit the size of the media that is to be printed. Place the side of the media to be copied facing upwards, and align it with the (MSI) Multi Sheet Inserter/Manual Feed Unit's side guide.
  • Page 236 Set up the media parameters on the printer Power Saver control panel. "Chapter 5 Setup Using the Printer Control Panel" Online Processing Error Manual Feed Mode Pause Menu Cancel Job Chapter 8 Replacing Paper...
  • Page 237: Chapter 9 Replenishing The Toner

    Chapter Chapter 0 Replenishing the Toner Chapter 9...
  • Page 238: Replenishing The Toner For Wide Format Printer

    Replenishing the Toner for Wide Format Printer If the message "Add Toner" appears on the printer control panel, replenish the toner. Observe the following when handling the toner. • When replenishing the toner, handle it carefully so as not to spill the toner on your clothes or around the machine.
  • Page 239 Insert the left side notch situated at the bottom of the toner cartridge into the end of the toner supply port. Then hold the toner cartridge vertically on top of the supply port. A l i g n t h e p r o t r u d i n g p a r t o f t h e c a r t r i d g e w i t h t h e n o t c h w h e n inserting it in the port.
  • Page 240 Chapter 9 Replenishing the Toner...
  • Page 241: Chapter 10 Paper Heater

    Chapter Chapter 0 Paper Heater Chapter 10...
  • Page 242: Using The Paper Heater

    10.1 Using the Paper Heater When the machine is used in high humidity environments the paper can become wrinkled. Switching on the paper heater can prevent paper from becoming wrinkled. Use the switch shown in the illustration to switch the paper heater on and off. Switch 10.1 Using the Paper Heater...
  • Page 243 10.1 Using the Paper Heater...
  • Page 244 Chapter 10 Paper Heater...
  • Page 245: Chapter 11 Troubleshooting

    Chapter Chapter 0 Troubleshooting Chapter 11...
  • Page 246: Setup Screen/Printer Control Panel

    11.1 Setup Screen/Printer Control Panel When machine failure is suspected in such cases where prints cannot be made or the results of the printout are defective, first check the messages displayed on the printer control panel. When an error code is displayed, press the < > and < > keys on the printer control panel at the same time.
  • Page 247: Poor Image Quality

    11.2 Poor Image Quality Observe the following recovery measures if the results of printing contain the quality defects listed below. Quality Defect Recovery The printout is soiled Check if the image density setting is correct or the document is soiled. Change the image density setting, and change the background suppression setting.
  • Page 248: Other Errors

    11.3 Other Errors Follow the instructions are provided to recover when the following errors occur. Error Recovery Nothing is displayed on the • Ascertain that the power supply where the machine printer control panel or is installed is normal, that the power plug has been control panel correctly plugged in, and that the power switch is •...
  • Page 249: Chapter 12 Clearing Paper Jams

    Chapter Chapter 0 Clearing Paper Jams Chapter 12...
  • Page 250: Paper Jam Display

    12.1 Paper Jam Display The location where a paper jam has occurred will be displayed on the control panel's setup screen. Clear paper jams using the message on the screen. 1. Open Scanner cover. 1. Raise the upper area of the printer.
  • Page 251: Document Jams

    12.2 Document Jams Remove jammed scanning documents with the following procedure. [Operations] Lift the top of the scanner until the lock on the left is engaged so the scanner cannot be closed. Pull the document towards you to remove it. Pull the document slowly.
  • Page 252: Jams In The Feeder (Roll Paper)

    12.3 Jams in the Feeder (Roll Paper) Paper jams in the roll paper feeder are caused by incorrect paper loading methods and defects in the paper feeding mechanism. Reload the paper in the feeder in accordance with the following procedure. [Operations] Open the media tray.
  • Page 253 Rotate the knob until the leading edge of the Window paper can be seen in the window. Rotate the knob at the rear if the jam occurred with the rear paper roll. Gently close the media tray until it is firmly in position as far back as it can go.
  • Page 254: Jams In The (Msi) Multi Sheet Inserter/Manual Feed Unit

    12.4 Jams in the (MSI) Multi Sheet Inserter/ Manual Feed Unit Remove paper jams from the (MSI) Multi Sheet Inserter/Manual Feed Unit following the procedure below. Steps 1 and 5 are required when using the combination unit. [Operations] Lift up the scanner document table until it is locked and cannot be closed.
  • Page 255 Close the cover of the manual insertion unit. Lift the lock lever in the middle back of the scanner document table, and then close the document table. 12.4 Jams in the (MSI) Multi Sheet Inserter/Manual Feed Unit...
  • Page 256: Paper Jams In The Printer And Ejection Port

    12.5 Paper Jams in the Printer and Ejection Port Remove paper jams from the printer and ejection port in accordance with the following instructions. [Operations] Lift up the lever situated on the left-hand side of the printer. Use both hands to lift up the top of the unit. The top of the unit cannot be lifted if the scanner's lock has been released with the combination unit.
  • Page 257 Pull the jammed paper slowly towards you to remove it. • Avoid damaging the paper. • Do not touch any of the high- temperature components in the machine when removing paper jams. Pull the green stopper to the front. Grasp the document table with both hands and gently lower it firmly into place.
  • Page 258 Chapter 12 Clearing Paper Jams...
  • Page 259: Chapter 13 Specifications

    Chapter Chapter 0 Specifications Chapter 13...
  • Page 260: Main Specifications

    13.1 Main Specifications Supported data formats • HPGL system : HP-GL, HP-GL2, and HP-RTL • Versatec system : Versatec Random Format (VRF), Versatec Color Graphic Language (VCGL), and FXMMR • Tag Image File Format (TIFF) system: Conforming to TIFF version 6.0 •...
  • Page 261: Ethernet Connection

    Host system interfaces TCP/IP Physical interface: 100Base-TX and 10Base-T (Transfer speed Manual selection, automatic selection) Maximum transfer speed: 100 Mbps and 10 Mbps Data link: Ethernet version 2 RS232C Physical interface: EIA-232-E conformant to RS-232C serial Maximum transfer speed: 38400 bps Maximum cable length: 15 m Centronics...
  • Page 262 Standard sizes and drawing areas Standard Series Dimensions Drawing area (dots) size × × 1,189 mm 19,872 28,064 × 841 mm 14,016 × 19,872 × × ISO A series 594 mm 9,920 14,016 × 420 mm 7,008 × 9,920 × 297 mm 4,960 ×...
  • Page 263 Number of sheets frame Configuration memory 512 MB 6030 Extended/6050 Standard 1 GB 6030/6050 Extended Frame memory - Maximum number of spools indicates the number of spools that are developed into bit map. The print entry data is spooled in hard disk separately from the memories.
  • Page 264: Media Specifications

    13.2 Media Specifications • For sharp image copying by 6030/6050 Wide Format, use media recommended by our company. • To prevent paper jams or uneven printing, do not use creased, wrinkled, or curled media. It may result in a media jam and white blotches on copies.
  • Page 265: Machine Specifications

    99 sheets maximum Copy speed A0 size : 5 sheets/min or higher (6050 Wide Format) A0 size : 3 sheets/min or higher (6030 Wide Format) Scan length Maximum : 15 m (at 100% scaling) Media feeding Auto paper feed from roll...
  • Page 266 No power is consumed in the output section and printer when the main power switch is OFF even if the power plug is connected to the power source. * Maximum length will differ in accordance with the amount of memory installed. Xerox 6030/6050 Wide Format Amount of A0 size...
  • Page 267: Appendixes

    Appendixes...
  • Page 268: Appendix 1 Connector Specifications

    Appendix 1 Connector Specifications RS-232C pin assignment PIN No. Controller side Signal name Wiring Host side Straight cable Cross cable [-] indicates no wiring. Both sides are male pins. Centronics pin assignment Printer Side (36-pin Amphenol half-pitch type) Terminal Terminal Signal name Signal name Pin connection...
  • Page 269 Host Side (36-pin Amphenol type) Terminal Terminal Signal name Signal name Pin connection nStrobe Data 1 Data 2 Data 3 Data 4 Data 5 Data 6 Data 7 Data 8 nAck Busy Perror Select nlnit nAutoFd nFault Logiv GND Chassis GND Peripheral nSelectln Logic High...
  • Page 270: Appendix 2 Hp-Gl/Hp-Gl2 Command List

    Appendix 2 HP-GL/HP-GL2 Command List This section explains the HP-GL and HP-GL/2 command support status that are unique to 6030/6050 Wide Format. Command fully supported. Activates different actims from other ordinary commands. (Meaning in [ ]) Command not supported and ignored.
  • Page 271 6030/6050 Com- Command Meaning and action HP-GL HP-GL/2 mand Wide Format Instructs the start of plotting. Outputs a label by overlaying on job log and plot output. Sets an auxiliary character set. Specifies character smoothness. Specifies an outline font rendering method.
  • Page 272 6030/6050 Com- Command Meaning and action HP-GL HP-GL/2 mand Wide Format Specifies a font as the primary font. Specifies a font as the secondary font. Fills in a polygon registered in the polygon buffer. Feeds paper by one frame for long-axis plotting.
  • Page 273 Outputs the current position on the printer coordinate system and the pen up-down information. Outputs the current position instructed by the last command and the pen up-down information. [6030/ 6050 Wide Format: Always returns the standard value (0,0,0)] Outputs read coordinates. [Always returns the...
  • Page 274 6030/6050 Com- Command Meaning and action HP-GL HP-GL/2 mand Wide Format Specifies the paper size. y (HP-GL) y* (HP-GL/2) Specifies the fill spacing. Raises the pen. Specifies the pen width. Sets the plot quality. Fills in a square determined by the current pen position and the specified X and Y coordinates.
  • Page 275 6030/6050 Com- Command Meaning and action HP-GL HP-GL/2 mand Wide Format Specifies the length of ticks drawn on the coordinate axis. Draws a user-defined character. Draws a user-defined fill pattern. Creates a specified line pattern. Inactivates the VA command. Specifies the drawing speed.
  • Page 276: Appendix 3 Hp-Rtl Command List

    Appendix 3 HP-RTL Command List Command name Command Command Meaning and function Limit Starts processing the following data as Enter HPGL/2 Mode ESC % # B Transfer color an HP-GL2 command. palette ignored Enter PCL Mode ESC % # A Starts processing the following data as Transfer color palette ignored...
  • Page 277 Command name Command Command Meaning and function Limit Assign Color Index ESC * v # i|I Assigns a defined RGB parameter to an Index Number Number index number. Push/Pop Palette ESC * p # P Saves and restores palette information. Ignored Start Raster Graphics ESC * r # a|A Sets the controller to the raster mode and...
  • Page 278 Command name Command Command Meaning and function Limit Raster Line Path ESC * b # l/L 1. Indicates the vertical distance of an image updated by raster data submitted by the Row/Block command. 2. Indicates the vertical distance of the CAP moved by the Y Offset command.
  • Page 279: Appendix 4 Tiff Tag List

    Appendix 4 TIFF Tag List Tag ID Revision 6030/6050 Tag Name Wide Format 00FE NewSubfileType Bit 0: Low Resolution Image Bit 1: Multi-Page Image Bit 2: Transparency Mask 00FF SubfileType 1: Full Resolution Image 2: Reduced-Resolution Image 3: Multi-Page Image...
  • Page 280 Tag ID Revision 6030/6050 Tag Name Wide Format 5: CMYK 6: YCbCr 8: CIELab 0107 Thresholding 1: No Dithering or Halftoning 2: Dithering or Halftoning 3: Randomized-Processed Image 0108 CellWidth 0109 CellWidth 010A FillOrder 1: MGB 2: LSB 010D DocumentName...
  • Page 281 Tag ID Revision 6030/6050 Tag Name Wide Format 2: Planar Format (RRGGBB) 011D PageName 011E XPosition 011F YPosition 0120 FreeOffsets 0121 FreeByteCounts 0122 GrayResponseUnit 0123 GrayResponseCurve 0124 T4Options Bit 0: 2-dimensional Coding Bit 1: uncompressed mode Bit 2: add Other than Bit 1 and 2...
  • Page 282 Tag ID Revision 6030/6050 Tag Name Wide Format 0143 TileLength 0144 TileOffsets 0145 TileByteCounts 014C InkSet 014D InkNames 014E NumberOfInks 0150 DotRange 0151 TargetPrinter 0152 ExtraSamples 0153 SampleFormat 1: unsigned integer data 2: 2's complement signed integer data 3: IEEE formatting point...
  • Page 283 Tag ID Revision 6030/6050 Tag Name Wide Format 0214 ReferenceBlackWhite 8298 33432 Copyright Appendix 4 TIFF Tag List...
  • Page 284 Appendixes...
  • Page 285 Appendix 4 TIFF Tag List...
