Centreware Internet Services Screen Components - Xerox Wide Format 6705 System User Manual

5
Refer
5.2.4
The CentreWare Internet Services screen consists of three frames (separate screens).
The information displayed in each frame depends on the feature selected: [Status], [Job and Log], [Scan], [Print
Settings], [Properties], or [Support].
Clicking [Help] in the top frame displays the CentreWare Internet Services help which gives you an explanation of

Note
the service.
Left frame
5.2 CentreWare® Internet Services
174
When specifying a port number, enter the IP address or the Internet address followed by a colon ":" and

the assigned port number.
If you have enabled encrypted communication by selecting the [Enabled] check box under [Security] >

[SSL / TLS Settings] > [HTTP - SSL / TLS Communication] on the [Properties] tab, you need to enter the
address beginning "https" instead of "http" in the browser address field in order to access CentreWare
Internet Services.
IP address entry example
Example - https://192.168.1.1/
Internet address entry example
Example - https://myhost.example.com/
If authentication while attempting to log in as system administrator fails, the following message is

displayed in the right frame of web browser:
"Login failed."
If the number of times of failed attempts to log in as system administrator exceeds the limit allowed, the

following message is displayed in the right frame of web browser:
"Switch the machine Off and then On for System Administrator login."
If you encounter problems during setup, refer to "Problems with CentreWare Internet Services" (p. 259).


CentreWare Internet Services Screen Components

Top frame
Right frame
