Search Time-Out
Allows you to set the maximum waiting time for user search results in the range of 1 to 120 seconds in one second
increments.
The factory default is [30] seconds.
LDAP Server / Directory Service
Allows you to configure the LDAP parameters.
Primary Server - Name / Address
Specify the server name or IP address of the primary server.
Primary Server - Port Number
Specify the port number to connect to the primary server in the range of 1 to 65535.
The factory default is [389].
Secondary Server - Name / Address
Specify the server name or IP address of the secondary server.
Secondary Server - Port Number
Specify the port number to connect to the secondary server in the range of 1 to 65535.
The factory default is [389].
Authentication Method
Allows you to select the LDAP authentication method from [Direct Authentication] and [Authentication of User
Attributes].
9
Direct Authentication

Select this to allow the LDAP server to authenticate a user based on the entered User ID and password.
Authentication of User Attributes

Select this to allow the LDAP server to search for a user based on the value entered in the User ID field, which
should correspond to the attribute specified in [Attribute of entered User Name]. From among values assigned
to the found user, the value for the attribute specified in [Attribute of Login User Name] is used as the User ID for
jobs processed on the machine and the owner name for folders.
The factory default is [Direct Authentication].
Attribute of entered User Name
When the LDAP authentication method is set to [Authentication of User Attributes], from among attributes
registered on the LDAP server as User Attribute information, specify the attribute whose value is used as user name
on the control panel to log in to the machine. For example, when you want a user to enter the mail address, set
"mail". Up to 32 characters are allowed.
The factory default is [mail].
Attribute of Login User Name
From among attributes registered on the LDAP server as User Attribute information, specify the attribute whose
value is used as the User ID for jobs processed on the machine and the owner name for folders. Up to 32 characters
are allowed.
The factory default is [sAMAccountName].
Use Added Text String
Allows you to select whether to automatically add information specified in[Text String Added to User Name] to
authentication information entered on the control panel.
The factory default is [Disabled].
