9.4.5

Variable Length Settings

You can use this feature to set the default variable length to be used when [Variable Length] is specified on the
[Paper Cut Mode] screen under the Copy feature.
The default variable length can be set for individual paper sizes, in the range of 210 to 5,000 mm.
The factory defaults are:
Series
A series A0 Wide
A1 Wide
A2 Wide
A3 Wide
JIS B series B1 Wide
B2 Wide
B3 Wide
ISO B Series B1 Wide
B2 Wide
B3 Wide
Special A series 880mm Wide
620mm Wide
440mm Wide
310mm Wide
Arch series 36" Wide
30" Wide
24" Wide
18" Wide
15" Wide
12" Wide
ANSI Series 34" Wide
22" Wide
17" Wide
11" Wide
Item
1189mm
841mm
594mm
420mm
1030mm
728mm
515mm
1000mm
707mm
500mm
1240mm
880mm
620mm
440mm
1219mm
1066mm
914mm
610mm
533mm
457mm
1118mm
864mm
559mm
432mm
Factory Default
