Importing Scanned Data; Import From A Twain-Compliant Application - Xerox Wide Format 6705 System User Manual

5.5

Importing Scanned Data

This section describes three methods to import the documents stored in the machine's folder into your computer.
Refer to these subsections for details on each procedure.
Import from a TWAIN-compliant Application ...........................................................................................................................p. 191

 Importing from Stored File Manager 3.........................................................................................................................................p. 194
 Importing Using CentreWare Internet Services ........................................................................................................................p. 197
5.5.1

Import from a TWAIN-compliant Application

The following describes how to import the documents stored in the machine's folder into your application.
To import the documents stored in the machine's folder, the scanner driver (to connect to network) needs to be used.
The scanner driver (to connect to network) is a software program to import documents (scanned data) stored in the
machine's folder to an application running on your computer via network connection.
To use the scanner driver (to connect to network), it must be installed on the computer.
You can install the scanner driver (to connect to network) from xerox.com.

Note
Before you can import documents from the machine's folder, you need to configure some settings such as

enabling a port. For information on how to do this, refer to "Setting Up the Store to Folder Feature" (p. 210). For
information on how to work with your application, refer to the documentation for the application.
For detailed information on items displayed in the dialog box, refer to the Help section of the scanner driver (to

Refer
connect to network) which can be displayed by clicking [Help].
Steps
St
1.
Start the application to which you want to import documents.
The application software must support TWAIN, a standard for scanners and other input devices.

Important
For notes and restrictions on using your application, refer to the "Readme" file for the scanner driver (to

Refer
connect to network).
2.
From the [File] menu, select the command for choosing a scanner (source).
3.
Select [FX Network Scanner 3 TWAIN] and click the
[Select] button.
4.
From the [File] menu, select the command for
importing images from the scanner.

5.5 Importing Scanned Data

5
191
