Summary of Contents for Xerox PHASER 6700

  • Page 1 6700 ® olor Laser Printer Phaser 6700 ® Service Manual Xerox Internal-Use Only...
  • Page 2 PDL/Emulation ................1-21 Phaser 6700 Printer Service Manual...
  • Page 3 Contents Reference Media Guidelines ..................A-2 Paper Characteristics .

  • Page 4: Manual Organization

    Manual Organization The Phaser 6700 Printer Service Manual contains these sections: Introductory, Safety, and Regulatory Information: This section contains important safety information and regulatory requirements. Chapter 1 - General Information: This section contains an overview of the printer’s operation, configuration, specifications, and consumables.

  • Page 5: Printer Overview

    General Information In the chapter..• Printer Overview • Printer Configurations • Parts of the Printer • Printer Options • Customer-Replaceable Maintenance Items • Specifications • External Interfaces Chapter...

  • Page 6: Theory Of Operation

    Theory of Operation In this chapter... • Print Process Overview • Sensors • Media Handling • Major Printer Components • Print Quality Controls • Optional Feeders • Finisher Overview • Major Finisher Components Chapter...
  • Page 7 Error Messages and Codes In this chapter... • Introduction • Servicing Instructions • Messages, Codes, and Procedures • Troubleshooting Procedures Chapter...

  • Page 8: Control Panel

    General Troubleshooting In this chapter... • Introduction • System Startup • Power On Self Test (POST) • Service Diagnostics • Control Panel Troubleshooting • DC Power Supply Troubleshooting • +24 VDC Interlock Switches • Abnormal Noises • Operating System and Application Problems Chapter...
  • Page 9 Print-Quality Troubleshooting In this chapter... • Print-Quality Overview • Checklist Before Troubleshooting Print-Quality • Print-Quality Troubleshooting • Test Prints • Image Specifications Chapter...
  • Page 10 Adjustments and Calibrations In this chapter... • Adjustments • NVRAM Utilities • Service Diagnostic NVRAM Utilities • Calibrations • Parameter Shadowing Chapter...
  • Page 11 Cleaning and Maintenance In this chapter... • Service Maintenance Procedure • Cleaning • Maintenance Chapter...

  • Page 12: Service Parts

    Service Parts Disassembly In this chapter... • Overview • Maintenance and Consumables • Print Engine Covers • Feeder / Registration Assembly • Right Door • Print Engine Electrical • Print Engine Drive • Print Engine Chassis • 550-Sheet Feeder • 1100-Sheet Feeder •...

  • Page 13: Parts List

    Parts List In this chapter... • Serial Number Format • Using the Parts List • Print Engine Parts • Feeder Parts Lists • Finisher Parts • Xerox Supplies and Accessories • Service Kits Chapter...
  • Page 14 Parts List 1.2 Print Engine Covers (2/3) 1 (with 2-4) (J302) (P212) 6 (with 7,8, Label YMCK) 24 (with 9-12,25) Front 13 (with 22) 17 (with 13-16,18-21) s6700-101 Printer Service Manual...
  • Page 15 Wiring In this chapter... • Printer Plug/Jack Designations • Printer Plug/Jack Locator Diagrams • Feeder Plug/Jack Designators • Feeder Plug/Jack Locator Diagrams • Finisher Plug/Jack Designators • Finisher Plug/Jack Locator Diagrams • Wiring Diagrams • Printer Wiring • Feeder Wiring •...

  • Page 16: Media Guidelines

    Reference In this chapter... • Media Guidelines • Firmware Update • Service Diagnostics Summary • NVM Parametric Values • Obtaining Serial Back Channel Traces • Mode Select Port • CRU End of Life Behavior • Acronyms and Abbreviations Appendix...
  • Page 17 Index right door 8-223 removal Right Side Door Open Switch 9-71 part number Right Side Door Switch 4-57 testing 2-28 sensor locations Size Switch Numerics 9-71 part number 4-55 testing take away clutch 1100-Sheet Feeder 4-59 testing Casters Take Away Sensor 9-67 part number 9-75...
  • Page 18 Background contamination cleaning 5-16 Banding 2-75 location Bias Housing Assembly part number 9-29 part number 8-63 removal 8-84 removal special functions 5-14 Black print testing Black Switching Sensor I – 2 Xerox Internal Use Only Phaser 6700 Printer Service Manual...

  • Page 19: Duplex

    9-89 part number removal Eject Roller Assembly Feed Rollers 8-261 removal 9-11 part number 2-21 Envelope Mode Feed Solenoid (Tray 1) 2-21 Envelope Mode Detection Sensor Phaser 6700 Printer Service Manual Xerox Internal Use Only I – 3...
  • Page 20 9-21 8-233 part number removal Feeder Horizontal Transport Cover Open Sensor 2-28 9-81 sensors part number 8-238 Feeder Assembly (Tray 2) removal 9-15 part number Horizontal Transport Drive 8-41 8-236 removal removal Feeder Board Horizontal Transport Drive Assembly 9-61 9-81 part number part number 8-200...

  • Page 21: Firmware Update

    Horizontal Transport Open Switch 9-37 part number 4-70 testing 8-122 removal HVPS 2-55 Full Stack Sensor 2-75 location 9-37 part number 2-76 operation 8-120 removal 9-29 part number 4-27 testing 8-86 removal Phaser 6700 Printer Service Manual I – 5...
  • Page 22 Laser Lens Cleaner 2-35 registration part number texture using weight Laser Unit 2-31 Media path 2-45 components Memory operation 1-15 maximum 9-29 part number 1-15 minimum 8-93 removal 1-15 specifications Left Cover al Use Only Phaser 6700 Printer Service Manual...

  • Page 23: Optional Feeders

    Repeating defects , 9-67, 9-89 part number 5-21 troubleshooting Photo Sensor Right Door 9-13 part number harness 9-101 Power Cord 9-23 part number 9-101 part number stopper strap Power On Self Test Phaser 6700 Printer Service M I – 7...

  • Page 24: Finisher

    9-19 2-21 part number Sheet Mode Right Door Assembly Size Switch 9-19 2-43 part number location 8-46 2-19 removal locations 9-13 Right Door Interlock Actuator part number 9-19 8-69 part number removal 8-44 4-31 removal testing Right Door Interlock Switch Skew 2-75 5-25...
  • Page 25 8-135 removal 4-52 testing Transfer Roller 2-12 operation Video Harness 9-25 part number 9-53 part number 8-11 removal 8-156 removal Transport Drive Assembly 5-19 Voids 9-91 part number Phaser 6700 Printer Service Manual Xerox Internal Use Only I – 9...
  • Page 26 9-31 part number 8-100 removal 4-34 testing 1-14 Warm up time Waste Auger , 2-16, 2-68 operation 9-33 part number 8-110 removal YMC Developer Drive Assembly Waste Toner Cartridge 9-47 part number , 2-16, 2-68 operation 8-167 removal 9-33 part number 4-50 testing 8-16...
