Drive Train (continued)

Coolant Strainer
23
(Cab Heater)
24 Air Cleaner Filter
Fuel/Water
25
Separator Filter
Driveline - Slip
26
Joints
27 Fuel Filter
NOTE: During replacement of the fuel filter, take note of the direction of the arrow. The arrow must point towards the fuel
filter
Grove
Figure Approved
No. Lubricant
Figure 9-4 ---
Figure 9-4 ---
Figure 9-4 ---
EP-MPG
Extreme
Pressure
Figure 9-4
Multipurpose
Grease
6829003477
Figure 9-4 ---
Published 11-10-2014, Control # 524-00
Lube
Lube Interval
Capacity
Clean strainer screen
after first 100 hours and
---
every 2000 hours or 12
months thereafter.
• Replace primary filter
element when
Engine Warning Light
blinks when ignition
key is turned on or
fault code 5576 or
---
3341 is displayed.
• Replace secondary
filter every third time
primary filter is
replaced.
• Drain water trap
every 10 hours or
daily.
---
• Change filter every
500 hours or 6
months.
Until
grease
500 hours or 3 months
extrudes
Change filter every 500
---
hours or 6 months
LUBRICATION
Application
Close shutoff valves.
Unscrew hex plug to
clean filter.
Remove panel
behind ladder to
access air filter.
Refer to Service
Manual
Separator filter is
located below the
fuel tank.
2 grease fittings
Fuel filter is located
on the top right
frame rail.
9
9-15
