Managing System
6.2

Using the CLI

6.2.1 Configuring the PoE Parameters Manually

Follow these steps to configure the basic PoE parameters:
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Downloaded from ManualsNet.com
configure
Enter global configuration mode.
power inline consumption power-limit
Specify the maximum power the PoE switch can supply globally.
power-limit : Specify the maximum power the PoE switch can supply.
For T1500-28PCT, the valid value ranges from 1 to 192 W. By default, the value is 192.
For TL-SG2210MP, the valid value ranges from 1 to 150 W. By default, the value is 150.
For TL-SG2210P, the valid value ranges from 1 to 58 W. By default, the value is 58.
interface { fastEthernet port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list }
Enter Interface Configuration mode.
port : Specify the Ethernet port number, for example 1/0/1.
port-list: Specify the list of Ethernet ports, for example 1/0/1-3, 1/0/5.
power inline supply { enable | disable }
Specify the PoE status for the corresponding port.
enable | disable: Enable or disable the PoE function. By default, it is enable.
power inline priority { low | middle | high }
Specify the PoE priority for the corresponding port.
low | middle | high: Select the priority level for the corresponding port. When the supply power
exceeds the system power limit, the switch will power off PDs on low-priority ports to ensure
stable running of other PDs. The default setting is low.
power inline consumption { power-limit | auto | class1 | class2 | class3 | class4 }
Specify the maximum power the corresponding port can supply.
power-limit | auto | class1 | class2 | class3 |
corresponding port can supply. The following options are provided: Auto represents that
the switch will allocate the maximum power that the port can supply automatically. Class1
represents 4 W, Class2 represents 7 W, Class3 represents 15.4 W and Class4 represents 30 W,
or you can enter a value manually. The value ranges from 1 to 300. It is in the unit of 0.1 watt.
For instance, if you want to configure the maximum power as 5 W, you should enter 50. By
default, it is Class4.
time-range name
Specify a time range for the port. Then the port will supply power only during the time range.
For how to create a time range, refer to
name: Specify the name of the time range.
search engine
PoE Configurations (Only for Certain Devices)
class4: Select or enter the maximum power the
Time Range Configuration.
User Guide 70
