Configuring ACL
5) In the Policy section, enable or disable the QoS Remark feature for the matched
packets. With this option enabled, configure the related parameters, and the remarked
values will take effect in the QoS processing on the switch.
Figure 2-14 Configuring QoS Remark
6) Click Apply.

Configuring Combined ACL Rule

Click Edit ACL for a Combined ACL entry to load the following page.
Figure 2-15 Configuring the Combined ACL Rule
In ACL Rules Table section, click
Downloaded from ManualsNet.com
Out of Band Select the action for the packets whose rate is beyond the specified rate.
None: The packets will be forwarded normally.
Drop: The packets will be discarded.
DSCP Specify the DSCP field for the matched packets. The DSCP field of the
packets will be changed to the specified one.
Local Priority Specify the local priority for the matched packets. The local priority of the
packets will be changed to the specified one.
802.1p Priority Specify the 802.1p priority for the matched packets. The 802.1p priority of
the packets will be changed to the specified one.
search engine
and the following page will appear.
ACL Configuration
User Guide 596
