Configuring QoS

3.1.2 Configuring Storm Control

Choose the menu QoS > Bandwidth Control > Storm Control to load the following page.
Figure 3-2 Configuring Storm Control
Follow these steps to configure the Storm Control function:
1) Select the desired port and configure the upper rate limit for forwarding broadcast
packets, multicast packets and UL-frames (Unknown unicast frames).
Downloaded from ManualsNet.com
Rate Mode Specify the Rate Mode for the broadcast threshold, multicast threshold and UL-
Frame threshold on the desired port.
kbps: The switch will limit the maximum speed of the specific kinds of traffic in
kilo-bits per second.
ratio: The switch will limit the percentage of bandwidth utilization for specific
kinds of traffic.
Broadcast Specify the upper rate limit for receiving broadcast packets. The valid values
Threshold (0- differ among different rate modes. The value 0 means the broadcast threshold is
1,000,000) disabled. The broadcast traffic exceeding the limit will be processed according to
the Action configurations.
Multicast Specify the upper rate limit for receiving multicast packets. The valid values
Threshold (0- differ among different rate modes. The value 0 means the multicast threshold is
1,000,000) disabled. The multicast traffic exceeding the limit will be processed according to
the Action configurations.
