Configuring MAC VLAN
egress rule as Untagged; for the ports connecting to other switch, set the egress rule
as Tagged.
2) On Switch 1 and Switch 2, bind the MAC addresses of the laptops to their
corresponding VLANs, and enable MAC VLAN for the ports.
Demonstrated with T1500-28PCT, the following sections provide configuration procedure
in two ways: using the GUI and using the CLI.
3.3

Using the GUI

■ Configurations for Switch 1 and Switch 2
The configurations of Switch 1 and Switch 2 are similar. The following introductions take
Switch 1 as an example.
1) Choose the menu L2 FEATURES > VLAN > 802.1Q VLAN > VLAN Config and click
tagged port 1/0/2 to VLAN 10. Click Create.
Downloaded from ManualsNet.com
to load the following page. Create VLAN 10, and add untagged port 1/0/1 and
