TP-Link TL-SG2210P Installation Manual

Installation Guide

8-Port Gigabit Smart PoE Switch with 2 SFP Slots
TL-SG2210P
Connection
AC Power Cord
DC Power Adapter
Internet
Configuration
1. To access the GUI of the switch, open a browser and type the default
management address http://192.168.0.1 in the address field of the
browser, then press the Enter key.
Note:
To log in to the switch, the IP address of your PC should be set in the
same subnet as that of the switch. The IP address is 192.168.0.x ("x" is
any number from 2 to 254). Subnet Mask is 255.255.255.0. For details,
please refer to Appendix B in the User Guide on the resource CD.
Ethernet Ports (1-8)
PoE Devices
PC
IP Camera
2. Enter admin for both the User Name and Password in the lower case
letters. Then click the Login button or press the Enter key.
3. After a successful login, the main page will appear as follows, and you
can click the menu on the left side to configure the corresponding
functions.
Note:
For more details about how to configure the switch, see the User Guide
on the resource CD.
For more information, please visit our website: http://www.tp-link.com
Note:
1. PoE ports can also connect to
non-PoE devices, but only transmit
data.
2. Maximum PoE power is 15.4W for
each PoE port and 53W for all PoE
AP IP Phone
ports.
7106504968 REV2.0.0
SFP Slots
