Configuring Protocol VLAN

The following example shows how to create an IPv6 protocol template:
Switch#configure
Switch(config)#protocol-vlan template name IPv6 frame ether_2 ether-type 86dd
Switch(config)#show protocol-vlan template
Index
-------
1
2
3
4
5
6
Switch(config)#end
Switch#copy running-config startup-config
2.2.3 Configuring Protocol VLAN
Follow these steps to configure protocol VLAN:
Step 1
Step 2
Step 3
Step 4
Downloaded from ManualsNet.com
Protocol Name Protocol Type
----------------- --------------------------------
IP EthernetII ether-type 0800
ARP EthernetII ether-type 0806
RARP EthernetII ether-type 8035
IPX SNAP
AT SNAP
IPv6 EthernetII ether-type 86DD
configure
Enter global configuration mode.
show protocol-vlan template
Check the index of each protocol template.
protocol-vlan vlan vid priority priority template index
Bind the protocol template to the VLAN.
vid : Enter the ID number of the 802.1Q VLAN that will be bound to the Protocol VLAN.
priority : Specify the 802.1p priority for the packets that belong to the protocol VLAN. The
switch will determine the forwarding sequence according this value. The packets with larger
value of 802.1p priority have the higher priority.
index : Specify the protocol template index.
show protocol-vlan vlan
Check the protocol VLAN index (entry-id) of each protocol group.
search engine
ether-type 8137
ether-type 809B
Protocol VLAN Configuration
User Guide 178
