Configuring System Logs
message is generated. To display the logs, the servers should run a log server software
that complies with the syslog standard.
Choose the menu MAINTENANCE > Logs > Remote Logs to load the following page.
Figure 2-2 Configuring the Remote Logs
Follow these steps to configure the information of remote log servers:
1) Select an entry to enable the server, and then set the server IP address and severity.
2) Click Apply.

2.1.3 Backing up the Logs

Choose the menu MAINTENANCE > Logs > Back Up Logs to load the following page.
Figure 2-3 Backing up the Log File
Click Back Up Logs to save the system logs as a file on your computer. If the switch system
breaks down, you can check the file for troubleshooting.
Downloaded from ManualsNet.com
Server IP Specify an IP address of the log server.
UDP Port Displays the UDP port used by the server to receive the log messages. The switch
uses standard port 514 to send log messages.
Severity Specify the severity level of the log messages sent to the selected log server.
Only log messages with a severity level value that is the same or lower than this
will be saved.
Status Enable or disable the log server.
search engine
System Logs Configurations
User Guide 825
