Configuring MAC VLAN
2.2

Using the CLI

2.2.1 Configuring 802.1Q VLAN

Before configuring MAC VLAN, create an 802.1Q VLAN and set the port type according to
network requirements. For details, refer to

2.2.2 Binding the MAC Address to the VLAN

Follow these steps to bind the MAC address to the VLAN:
Step 1
Step 2
Step 3
Step 4
Step 5
The following example shows how to bind the MAC address 00:19:56:8A:4C:71 to VLAN 10,
with the address description as Dept.A.
Switch#configure
Switch(config)#mac-vlan mac-address 00:19:56:8a:4c:71 vlan 10 description Dept.A
Switch(config)#show mac-vlan vlan 10
MAC-Addr
--------------
00:19:56:8A:4C:71
Switch(config)#end
Downloaded from ManualsNet.com
configure
Enter global configuration mode.
mac-vlan mac-address mac-addr vlan vlan-id [description descript ]
Bind the MAC address to the VLAN.
mac-addr : Specify the MAC address of the device in the format of xx:xx:xx:xx:xx:xx.
vlan-id : Enter the ID number of the 802.1Q VLAN that will be bound to the MAC VLAN.
descript : Specify the MAC address description for identification, with up to 8 characters.
show mac-vlan { all | mac-address mac-addr | vlan vlan-id }
Verify the configuration of MAC VLAN.
vid : Specify the MAC VLAN to be displayed.
end
Return to privileged EXEC mode.
copy running-config startup-config
Save the settings in the configuration file.
Name
-----------
Dept.A
search engine
Configuring 802.1Q
VLAN-ID
------------
10
MAC VLAN Configuration
VLAN.
User Guide 159
