Configuring Protocol VLAN
Step 5
Step 6
Step 7
Step 8
The following example shows how to bind the IPv6 protocol template to VLAN 10 and add
port 1/0/2 to protocol VLAN:
Switch#configure
Switch(config)#show protocol-vlan template
Index
--------
1
2
3
4
5
6
Switch(config)#protocol-vlan vlan 10 priority 5 template 6
Switch(config)#show protocol-vlan vlan
Index
--------
1
Switch(config)#interface gigabitEthernet 1/0/2
Switch(config-if)#protocol-vlan group 1
Switch(config-if)#show protocol-vlan vlan
Downloaded from ManualsNet.com
interface {fastEthernet port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list |
port-channel port-channel-id | range port-channel port-channel-list }
Enter interface configuration mode.
protocol-vlan group entry-id
Add the specified port to the protocol group.
entry-id: Protocol VLAN index.
end
Return to Privileged EXEC Mode.
copy running-config startup-config
Save the settings in the configuration file.
Protocol Name Protocol Type
------------------ --------------------------------
IP EthernetII ether-type 0800
ARP EthernetII ether-type 0806
RARP EthernetII ether-type 8035
IPX SNAP
AT SNAP
IPv6 EthernetII ether-type 86DD
Protocol-Name
--------------------
IPv6
search engine
ether-type 8137
ether-type 809B
VID Priority Member
------ ------ ------
10 0
Protocol VLAN Configuration
