The following example shows how to create an Event entry on the switch. Set the user
name as admin, the event type as Notify (set the switch to initiate notifications to the NMS),
and the owner as monitor:
Switch#configure
Switch(config)#rmon event 1 user admin description rising-notify type notify owner
monitor
Switch(config)#show rmon event
Index User
----- ----
1
Switch(config)#end
Switch#copy running-config startup-config

5.2.4 Configuring Alarm

Step 1
Step 2
Downloaded from ManualsNet.com
Description
-----------
admin rising-notify
configure
Enter Global Configuration Mode.
rmon alarm index stats-index sindex [ alarm-variable { revbyte | revpkt | bpkt | mpkt | crc-
align | undersize | oversize | jabber | collision | 64 | 65-127 | 128-255 | 256-511 | 512-1023 |
1024-1518}] [ s-type {absolute | delta}] [ rising-threshold r-threshold ] [ rising-event-index
r-event ] [ falling-threshold f-threshold ] [ falling-event-index f-event ] [ a-type {rise | fall |
all} ] [ owner owner-name ] [ interval interval ]
Configuring RMON alarm entries.
index: Specify the index of the Alarm entry, which ranges from 1 to 12. To configure multiple
indexes, enter a list of indexes separated by commas, or use a hyphen to indicates a range
of indexes. For example, 1-3, 5 indicates 1, 2, 3, 5.
sindex:
Specify the index of the related Statistics entry, which ranges from 1 to 65535.
revbyte | revpkt | bpkt | mpkt | crc-align | undersize | oversize | jabber | collision | 64 | 65-
127 | 128-255 | 256-511 | 512-1023 | 1024-1518:
switch will monitor the specified variable in sample intervals and act in the set way when the
alarm is triggered. The default variable is revbyte.
revbyte means total number of received bytes;
packets; bpkt means total number of broadcast packets.
multicast packets;
within a size of 64 to 1518 bytes;
oversize means packets that are larger than 1518 bytes;
sent when port collisions occur;
64 | 65-127 | 128-255 | 256-511 | 512-1023 | 1024-1518
the specified size.
search engine
Type Owner State
---- ----- -----
Notify monitor Enable
crc-align means packets that contain FCS Error or Alignment Error,
undersize means packets that are smaller than 64 bytes;
collision means the collision times in the network segment;
RMON Configurations
Choose an alarm variable to monitor. The
revpkt means total number of received
mpkt means total number of
jabber means packets that are
means total number of packets of
