Configuring Layer 2 Multicast
Last Member Query Interval:
Last Member Query Count:
General Query Source IP:
...
Switch(config)#end
Switch#copy running-config startup-config

3.2.3 Configuring MLD Snooping for Ports

Follow these steps to configure MLD Snooping for ports:
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
The following example shows how to enable MLD Snooping and fast leave for port 1/0/1-3:
Switch#configure
Switch(config)#interface range fastEhternet 1/0/1-3
Switch(config-if-range)#ipv6 mld snooping
Downloaded from ManualsNet.com
configure
Enter global configuration mode.
interface {fastEthernet port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list |
port-channel port-channel-id | range port-channel port-channel-list }
Enter interface configuration
ipv6 mld snooping
Enable MLD Snooping for the port. By default, it is enabled.
ipv6 mld snooping immediate-leave
(Optional) Enable Fast Leave on the specified port.
Fast Leave can be enabled on a per-port basis or per-VLAN basis. When enabled on a per-port
basis, the switch will remove the port from the corresponding multicast group of all VLANs
before forwarding the done message to the querier.
You should only use Fast Leave for a port when there is a single receiver connected to the
port. For more details about Fast Leave, see
show ipv6 mld snooping interface [fastEthernet [ port-list ] | gigabitEthernet [ port-list ] |
ten-gigabitEthernet [ port-list ] | port-channel [ port-channel-list ]] basic-config
Show the basic MLD Snooping configuration on the specified port(s) or of all the ports.
end
Return to privileged EXEC mode.
copy running-config startup-config
Save the settings in the configuration file.
search engine
2
3
fe80::1
mode.
"3.2.2 Configuring MLD Snooping for
MLD Snooping Configuration
VLANs".
User Guide 242
