Configuring LLDP
Step 6
Step 7
Step 8
Step 9
The following example shows how to configure the port 1/0/1. The port can receive and
transmit LLDP packets, its notification mode is enabled and the outgoing LLDP packets
include all TLVs.
Switch#configure
Switch(config)#lldp
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#lldp receive
Switch(config-if)#lldp transmit
Switch(config-if)#lldp snmp-trap
Switch(config-if)#lldp tlv-select all
Switch(config-if)#show lldp interface gigabitEthernet 1/0/1
LLDP interface config:
gigabitEthernet 1/0/1:
Admin Status: TxRx
SNMP Trap: Enabled
TLV
---
Port-Description
System-Capability
System-Description
System-Name
Management-Address
Downloaded from ManualsNet.com
lldp tlv-select
(Optional) Configure the TLVs included in the outgoing LLDP packets. By default, the
outgoing LLDP packets include all TLVs.
show lldp interface { fastEthernet port | gigabitEthernet port | ten-gigabitEthernet port }
Display LLDP configuration of the corresponding port.
end
Return to Privileged EXEC Mode.
copy running-config startup-config
Save the settings in the configuration file.
Status
------
Yes
Yes
Yes
Yes
Yes
search engine
LLDP Configurations
User Guide 367
