Power
indicator
Sample port connector
o
port connector
P
Analyzer power indicator

Side Panel

The side panel of the Master Unit contains the gas ports described below. Auxiliary units do not con-
tain gas ports.
246-42800-01 - Aug 2013
For installing the sample tube.
For installing a (saturation pressure) tube.
o
P
Turns on and flashes green while the analyzer is
attempting to communicate with the computer. Once
communications are established, it remains solid green.
Controls, Indicators, and Connectors
Sample port
connector
o port connector
P
Gas inlet ports
