ASAP 2460 Operator's Manual
• Double-click on the valve or elevator symbol.
• Select the valve or elevator symbol and press the
Valves
Valve
1 through 6
7
8
9
10
11 through 16
17
18
21 through 26
Unmarked
Transducers
Dewar positions
246-42800-01 - Aug 2013
Spacebar.
System valves and their functions are listed below.
Actions: Open, Close, Pulse
Pulse briefly opens and closes (or vice versa) the valve.
Description
Sample ports
Lower manifold isolation
Sample ports unrestricted vacuum
o
p ports access
o
p ports unrestricted vacuum
o
p ports
Upper manifold isolation
Gas inlets unrestricted vacuum
Gas inlets
Servo
Each sample port and Psat port contains a 1000-mmHg
transducer. The transducer readings display next to the ports.
The dewar can be raised, lowered, or stopped.
Indicates the dewar is being raised; note the position of the
arrow in the center of the dewar symbol.
Indicates the dewar is being lowered; note the position of the
arrow in the center of the dewar symbol.
Indicates the dewar is stopped in the raised position.
Start Micropore Analysis
4-15
