Definition of directions
The directions "forwards" (1), "backwards" (3),
"right" (2) and "left" (4) refer to the installation
position of the parts as seen from the driver's
compartment; the load is to the front.

Schematic views

View of functions and operating proce-
dures
At many points in this documentation, the
(mostly sequential) operation of certain func-
tions or operating procedures is explained.
Schematic diagrams of a counterbalance
truck are used to illustrate these procedures.
NOTE
These schematic views are not representative
of the structural state of the documented truck.
The views are used solely for the purpose of
clarifying procedures.
