Multi-lever operation
1
8
1
Drive direction switch
2
"Lift/lower" operating lever
"Tilt" operating lever
3
4
Operating lever for attachments (variant)
5
Function key for the "5th function" (variant)
NOTE
The drive direction switch (1) does not function
in the dual-pedal version (variant).
Operating devices and display elements
3
2
6
7
8
56368011531 EN - 06/2019 - 02
5
6
4
7
Operating lever for attachments (variant)
Function key for the "5th or 6th function"
(variants)
Signal horn button
