RX20-20 swing axle VDI datasheet

RX20-20 swing axle VDI
datasheet
NOTE
This VDI datasheet specifies only the technical
values for trucks with standard equipment.
Different tyres, lift masts, additional units etc.
can produce different values.
Key data
Model
Type number
Manufacturer
Drive
Operation
Rated capacity/load
Load centre of gravity distance
Load distance
Wheelbase
.
Weights
Model
Type number
Net weight
Front axle load, laden
Rear axle load, laden
Front axle load, unladen
Rear axle load, unladen
.
Wheels, chassis frame
Model
Type number
Tyres
Tyre size, front
422
STILL GmbH
Q (kg)
c (mm)
x (mm)
y (mm)
kg
kg
kg
kg
kg
56368011531 EN - 06/2019 - 02
RX20-20P
6230
Electric
Seat
2000
500
388
1429
RX20-20P
6230
3474
4858
616
1616
1858
RX20-20P
6230
Superelastic
200/50-10
Technical data
RX20-20PL
6231
STILL GmbH
Electric
Seat
2000
500
388
1537
RX20-20PL
6231
3449
4851
598
1696
1754
RX20-20PL
6231
Superelastic
200/50-10
